McCormick C75-110 Max (T3)
Manufacturer
Models
McCormick C75 Max (T3), McCormick C80 Max (T3), McCormick C90 Max (T3), McCormick C100 Max (T3), McCormick C100 Max (T3), McCormick C105 Max (T3), McCormick C110 Max (T3)
Years
2007-
Info
In the C-Max (T3) lineup, Perkins engines were used. Initially, the smallest model was a 3-cylinder, but it was soon dropped from the selection. The basic transmission was still 12+12, but in most countries, a mechanical quick-shift was standard, which doubled the number of forward gears. In the Power Shuttle version, the quick-shift was hydraulic, as were the direction reverser and additionally the PTO and four-wheel drive engagement. The front axle had separate brakes as standard. The cab remained almost unchanged and featured a small central hump. The basic equipment was minimal, but optional extras included, among other things, increased lifting capacity, a pneumatic seat, and air conditioning.
In the Landini lineup, the same tractor was marketed under the name Powerfarm.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | McCormick C75 Max (T3) | McCormick C80 Max (T3) | McCormick C90 Max (T3) | McCormick C100 Max (T3) | McCormick C100 Max (T3) | McCormick C105 Max (T3) | McCormick C110 Max (T3) |
|---|---|---|---|---|---|---|---|
| Options | |||||||
| Manufacturer name | McCormick | McCormick | McCormick | McCormick | McCormick | McCormick | McCormick |
| Imported to Finland | No | No | No | No | No | No | No |
| Years | 2007-09 | 2007- | 2007- | 2007-09 | 2009- | 2007-09 | 2009- |
| First year sold | 2007 | 2007 | 2007 | 2007 | 2009 | 2007 | 2009 |
| Last year sold | 2009 | - | - | 2009 | - | 2009 | - |
| Engine model | 1103D-33T | 1104D-44 | 1104D-44T | 1104D-44T | 1104D-44T | 1104D-44T | 1104D-44TA |
| Cyl/Turbo/Intercooler | 3T | 4 | 4T | 4T | 4T | 4T | 4TI |
| Displacement | 3300 cm³ | 4400 cm³ | 4400 cm³ | 4400 cm³ | 4400 cm³ | 4400 cm³ | 4400 cm³ |
| Bore x stroke | 105×127 mm | 105×127 mm | 105×127 mm | 105×127 mm | 105×127 mm | 105×127 mm | 105×127 mm |
| Rated power hp/rpm ISO | 68/2200 | 74/2200 | 83/2200 | 92,5/2200 | 92,5/2200 | 98,6/2200 | 102/2200 |
| Rated power | - | - | - | - | - | - | - |
| Rated speed | - | - | - | - | - | - | - |
| Torque Nm/rpm ISO | 222/1400 | 256/1400 | 345/1400 | 384/1400 | 393/1400 | 384/1400 | 416/1400 |
| Gears | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 |
| Synchronized gears | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 | 12+12/24+12 |
| Powershift gears | -/mech. | -/mech. | -/mech./hydr. | -/mech./hydr. | -/mech./hydr. | -/mech./hydr. | -/mech./hydr. |
| Reverser | mech. | mech. | mech./hydr. | mech./hydr. | mech./hydr. | mech./hydr. | mech./hydr. |
| Speeds in km/h | 2,0-40 | 2,0-40 | 2,0-40 | 2,0-40 | 2,0-40 | 2,0-40 | 2,0-40 |
| Hydr. flow l/min | 52 l/min | 52 l/min | 52 l/min | 52 l/min | 52 l/min | 52 l/min | 52 l/min |
| Hydraulic pressure | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 2600 (3700) kg | 2600 (3700) kg | 2600 (3700) kg | 2600 (3700) kg | 2600 (3700) kg | 2600 (4350) kg | 2600 (4350) kg |
| PTO speeds | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 8.2 | 8.4 | 8.4 | 8.4 | 8.4 | 8.4 | 8.4 |
| Front tyres 2WD | 7.50-16 | 10.0-16 | 10.0-16 | 10.0-16 | 10.0-16 | 10.0-16 | 10.0-16 |
| Front tyres 4WD | 360/70R24 | 360/70R24 | 360/70R24 | 360/70R24 | 360/70R24 | 360/70R24 | 360/70R24 |
| Rear tyres 2WD | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 |
| Rear tyres 4WD | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 | 420/85R34 |
| Weight 4WD | 2920 kg | 3480 kg | 3480 kg | 3480 kg | 3480 kg | 3600 kg | 3600 kg |
| Height with cab | 251 cm | 252 cm | 252 cm | 256 cm | 256 cm | 256 cm | 256 cm |
| Length (2WD/4WD) | 399 cm | 414 cm | 414 cm | 414 cm | 414 cm | 416 cm | 416 cm |
| Wheelbase (2WD/4WD) | 219/217 cm | 234/232 cm | 234/232 cm | 234/232 cm | 234/232 cm | 237/234 cm | 237/234 cm |
| Fuel tank | 102 l | 102 l | 102 l | 102 l | 102 l | 102 l | 102 l |
| Solid cab | x | x | x | x | x | x | x |
| Diff. lock | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. | opt. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
