McCormick X7.417-X7.618 / Landini 7-165 – 7-180

Manufacturer
Models
McCormick X7.417, Landini 7-165, McCormick X7.418, Landini 7-175, McCormick X7.617, Landini 7-160, McCormick X7.618, Landini 7-180
Years
2022-
Info

For 2022, the short–wheelbase McCormick X7 and Landini 7 models returned with Stage V–compliant NEF engines and redesigned hoods. There were two four-cylinder and two six-cylinder versions, with power outputs ranging from 165 to 175 hp. The standard transmission was the new ZF Terramatic—known as P6-Drive on McCormick and Robo-Six on Landini—with six powershift steps across five ranges. The transmission’s automation also handled range shifting. Alongside these, VT-Drive models with ZF continuously variable transmissions remained available; those had four base “gears.”

Hydraulics now always feature an adjustable-capacity pump delivering either 123 or 160 l/min, while electronic control blocks are offered as an option. Lift capacity is rated at either 6,400 or 9,300 kg. Cab noise is specified at 70 dB, and a control-armrest is now standard.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelMcCormick X7.417Landini 7-165McCormick X7.418Landini 7-175McCormick X7.617Landini 7-160McCormick X7.618Landini 7-180
Imported to FinlandYesYesYesYesYesYesYesYes
Years2022-2022-2022-2022-2022-2022-2022-2022-
Engine modelNEF 45NEF 45NEF 45NEF 45NEF 67NEF 67NEF 67NEF 67
Cyl/Turbo/Intercooler4TI4TI4TI4TI6TI6TI6TI6TI
Displacement4485 cm³4485 cm³4485 cm³4485 cm³6728 cm³6728 cm³6728 cm³6728 cm³
Bore x stroke104×132 mm104×132 mm104×132 mm104×132 mm104×132 mm104×132 mm104×132 mm104×132 mm
Rated power--------
Max power--------
Torque--------
Gears30+1530+1530+15/stepless30+15/stepless30+1530+1530+15/stepless30+15/stepless
Synchronized gears30+1530+1530+15/stepless30+15/stepless30+1530+1530+15/stepless30+15/stepless
Powershift gears6-step6-step6-step/stepless6-step/stepless6-step6-step6-step/stepless6-step/stepless
Reverserhydr.hydr.hydr.hydr.hydr.hydr.hydr.hydr.
Max. speed 40 (50) km/h40 (50) km/h40 (50) km/h40 (50) km/h40 (50) km/h40 (50) km/h40 (50) km/h40 (50) km/h
Hydr. flow l/min123 (160) l/min123 (160) l/min123 (160) l/min123 (160) l/min123 (160) l/min123 (160) l/min123 (160) l/min123 (160) l/min
Hydraulic pressure206 bar206 bar206 bar206 bar206 bar206 bar206 bar206 bar
Lift controlselec.elec.elec.elec.elec.elec.elec.elec.
Lift capacity6400/9300 kg6400/9300 kg6400/9300 kg6400/9300 kg6400/9300 kg6400/9300 kg6400/9300 kg6400/9300 kg
PTO speeds540/750/1000/ 1400540/750/1000/ 1400540/750/1000/ 1400540/750/1000/ 1400540/750/1000/ 1400540/750/1000/ 1400540/750/1000/ 1400540/750/1000/ 1400
Brakeswet discwet discwet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD10.810.810.810.810.810.810.810.8
Front tyres 4WD480/65R28480/65R28480/65R28480/65R28480/65R28480/65R28480/65R28480/65R28
Rear tyres 4WD600/65R38600/65R38600/65R38600/65R38600/65R38600/65R38600/65R38600/65R38
Weight 4WD6400 kg6400 kg6400/6700 kg6400/6700 kg6700 kg6700 kg6700/7000 kg6700/7000 kg
Height with cab294 cm294 cm294 cm294 cm294 cm294 cm294 cm294 cm
Length (2WD/4WD)507 cm507 cm507 cm507 cm526 cm526 cm526 cm526 cm
Wheelbase (2WD/4WD)265 cm265 cm265 cm265 cm176 cm176 cm176 cm176 cm
Fuel tank280+AB46 l280+AB46 l280/350+AB46 l280/350+AB46 l320+AB46 l320+AB46 l320/350+AB46 l320/350+AB46 l
Cab noise level70 dB70 dB70 dB70 dB70 dB70 dB70 dB70 dB
Solid cabxxxxxxxx
Diff. lockdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogs
Autom. differential locksxxxxxxxx
Air suspension seatxxxxxxxx
Air conditioningxxxxxxxx
Creeper gearopt.opt.opt./xopt./xopt.opt.opt./xopt./x
