John Deere 840-1140
Manufacturer
Models
John Deere 840, John Deere 940, John Deere 1040, John Deere 1140, John Deere 1040, John Deere 1140
Years
1980-87
Info
The 40-series European tractors were introduced at the end of 1979. All 3-cylinder models were now 2.9 liters. The transmission was the familiar 8+4 (with Hi-Lo quick shift, making it 16+8), but it was now synchronized. The quick shift had been improved so that the tractor could now be started by towing and parked with the gear engaged.
The cab was the familiar Sekura product, and the gear levers were positioned in the center. The steering in the three-cylinder models was not hydrostatic. In 1981, the front axle was replaced with a more agile one.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | John Deere 840 | John Deere 940 | John Deere 1040 | John Deere 1140 | John Deere 1040 | John Deere 1140 |
|---|---|---|---|---|---|---|
| Options | ||||||
| Manufacturer name | John Deere | John Deere | John Deere | John Deere | John Deere | John Deere |
| Imported to Finland | No | No | Yes | Yes | Yes | Yes |
| Years | 1980-86 | 1980-86 | 1980-81 | 1980-81 | 1981-87 | 1981-87 |
| First year sold | 1980 | 1980 | 1980 | 1980 | 1981 | 1981 |
| Last year sold | 1986 | 1986 | 1981 | 1981 | 1987 | 1987 |
| Engine model | 3179 | 3179 | 3179DL01 | 3179DL01 | 3179DL01 | 3179DL01 |
| Cyl/Turbo/Intercooler | 3 | 3 | 3 | 3 | 3 | 3 |
| Displacement | 2940 cm³ | 2940 cm³ | 2940 cm³ | 2940 cm³ | 2940 cm³ | 2940 cm³ |
| Bore x stroke | 106,5×110 mm | 106,5×110 mm | 106,5×110 mm | 106,5×110 mm | 106,5×110 mm | 106,5×110 mm |
| Rated power hp/rpm DIN | 35/2400 | 44/2400 | 50/2500 | 56/2500 | 50/2500 | 56/2500 |
| Rated power | 35 | 44 | 50 | 56 | 50 | 56 |
| Rated speed | 2400 | 2400 | 2500 | 2500 | 2500 | 2500 |
| Torque Nm/rpm DIN | 135/1300 | 154/1300 | 172/1400 | 185/1400 | 172/1400 | 185/1400 |
| Gears | 8+4 | 8+4 | 8+4/16+8 | 8+4/16+8 | 8+4 | 8+4/16+8 |
| Synchronized gears | 8+4 | 8+4 | 8+4/16+8 | 8+4/16+8 | 8+4 | 8+4/16+8 |
| Powershift gears | opt. | opt. | opt. | opt. | opt. | opt. |
| Speeds in km/h | 2,0-23,5 | 2,0-23,5 | 3,4-31,5 | 3,4-31,5 | 3,4-31,5 | 3,4-31,5 |
| Max. speed | 25 km/h | 25 km/h | - | - | - | - |
| Hydr. flow l/min | 23 l/min | 23 l/min | 47 l/min | 47 l/min | 47 l/min | 47 l/min |
| Hydraulic pressure | 190 bar | 190 bar | 190 bar | 190 bar | 190 bar | 190 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 2215 kg | 2215 kg | 2350 kg | 2350 kg | 2350 kg | 2350 kg |
| PTO speeds | 540 | 540 | 540 | 540 | 540 | 540 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | mech. | power | power | power | power | power |
| Turning circle m 2WD | 6.2 | 6.2 | 6.6 | 6.6 | 6.6 | 6.6 |
| Turning circle m 4WD | - | - | 9 | 9 | 8.2 | 8.2 |
| Front tyres 2WD | 6,50-16 | 6,50-16 | 7,50-16 | 7,50-16 | 7,50-16 | 7,50-16 |
| Front tyres 4WD | - | - | 9.50-24 | 11.2-24 | 9.50-24 | 11.2-24 |
| Rear tyres 2WD | 12,4-28 | 12,4-32 | 12,4-36 | 13,6-36 | 12,4-36 | 13,6-36 |
| Rear tyres 4WD | - | - | 12.4-36 | 13.6-36 | 12.4-36 | 13.6-36 |
| Weight 2WD | 2270 kg | 2270 kg | 2890 kg | 2940 kg | 2890 kg | 2760 kg |
| Weight 4WD | - | - | 3160 kg | 3210 kg | 3160 kg | 3070 kg |
| Height with cab | 239 cm | 239 cm | 244 cm | 245 cm | 244 cm | 245 cm |
| Length (2WD/4WD) | 351 cm | 351 cm | 351/364 cm | 351/364 cm | 351/364 cm | 351/364 cm |
| Wheelbase (2WD/4WD) | 189 cm | 189 cm | 205 cm | 205/206 cm | 205 cm | 205/206 cm |
| Fuel tank | 78 l | 78 l | 78 l | 78 l | 78 l | 78 l |
| Cab noise level | 90 dB | - | 84.5 dB | 84.5 dB | 84.5 dB | 84 dB |
| Solid cab | (x) | (x) | x | x | x | x |
| Diff. lock | opt. | opt. | - | - | friction lock | friction lock |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
