Siirry sivupalkkiinSiirry alaosaanJohn Deere 6530-6930






The range of basic models in the 6030 series extended to higher power classes than the preceding 6020 SE series. The largest models, the 6830 and 6930, were equipped with load-sensing hydraulics and a 20+20 gear transmission. All models featured 2-valve technology. The basic transmission in the smaller 6-cylinder models was 16+16, but for Finland these models were imported with 24+24 transmissions. There were also many versions of the hydraulics. The standard lifting capacity was 5,100 kg, but the versions mainly imported to Finland had lifting capacities of 5,900 kg and 6,600 kg. Hydraulic output was 54, 63, or 81 liters per minute, and for the largest models' load-sensing pump, 81 or 110 liters per minute. Finland again primarily ordered the most powerful hydraulics. The brochure listed the cab noise level in the 6-cylinder models as 73 dB.
In the autumn of 2009, the 6530 was replaced by the 4-cylinder 6534, in which a 4-cylinder engine was installed into the frame of the 6-cylinder model. The wheelbase and other dimensions remained the same as in the 6-cylinder model. At the same time, the 6630 and 6830 models received an additional 5 horsepower, and the rpm at maximum torque decreased.
This is an automated translation. Please report any issues in the translation.
| Model | John Deere 6530 | John Deere 6630 | John Deere 6830 | John Deere 6930 | John Deere 6534 | John Deere 6630 | John Deere 6830 | John Deere 6930 |
|---|---|---|---|---|---|---|---|---|
| Manufacturer name | John Deere | John Deere | John Deere | John Deere | John Deere | John Deere | John Deere | John Deere |
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 2007-09 | 2007-09 | 2007-09 | 2007-09 | 2009-12 | 2009-12 | 2009-12 | 2009-12 |
| Engine model | 6068 T 2V-CR | 6068 T 2V-CR | 6068 T 2V-CR | 6068 T 2V-CR | 4045 T 4V-CR | 6068 T 2V-CR | 6068 T 2V-CR | 6068 T 2V-CR |
| Cyl/Turbo/Intercooler | 6TI | 6TI | 6TI | 6TI | 4TI | 6TI | 6TI | 6TI |
| Displacement | 6788 cm³ | 6788 cm³ | 6788 cm³ | 6788 cm³ | 4530 cm³ | 6788 cm³ | 6788 cm³ | 6788 cm³ |
| Bore x stroke | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm |
| Rated power | - | - | - | - | - | - | - | - |
| Max power | - | - | - | - | - | - | - | - |
| Torque | - | - | - | - | - | - | - | - |
| Gears | 24+24 | 24+24 | 20+20 | 20+20 | 24+24 | 24+24 | 20+20 | 20+20 |
| Synchronized gears | 24+24 | 24+24 | 20+20 | 20+20 | 24+24 | 24+24 | 20+20 | 20+20 |
| Powershift gears | 4-speed | 4-speed | 4-speed | 4-speed | 4-speed | 4-speed | 4-speed | 4-speed |
| Reverser | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Speeds in km/h | 1,6-40 | 1,6-40 | 2,5-40 | 2,5-40 | 1,6-40 | 1,6-40 | 2,5-40 | 2,5-40 |
| Hydr. flow l/min | 81 l/min | 81 l/min | 110 l/min | 110 l/min | 81 l/min | 81 l/min | 110 l/min | 110 l/min |
| Hydraulic pressure | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar |
| Lift controls | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Lift capacity | 5900 kg | 6620 kg | 7400 kg | 7400 kg | 5900 kg | 6620 kg | 7400 kg | 7400 kg |
| PTO speeds | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 10.2 | 10.2 | 10.4 | 10.4 | 10.2 | 10.2 | 10.4 | 10.4 |
| Front tyres 4WD | 14.9R28 | 14.9R28 | 16.9R28 | 16.9R28 | 14.9R28 | 14.9R28 | 16.9R28 | 16.9R28 |
| Rear tyres 4WD | 18.4R38 | 18.4R38 | 20.8R38 | 20.8R38 | 18.4R38 | 18.4R38 | 20.8R38 | 20.8R38 |
| Weight 4WD | 5230 kg | 5230 kg | 5880 kg | 5880 kg | 4950 kg | 5230 kg | 5880 kg | 5880 kg |
| Height with cab | 283 cm | 283 cm | 290 cm | 290 cm | 283 cm | 283 cm | 290 cm | 290 cm |
| Length (2WD/4WD) | 473 cm | 473 cm | 476 cm | 476 cm | 473 cm | 473 cm | 476 cm | 476 cm |
| Wheelbase (2WD/4WD) | 265 cm | 265 cm | 265 cm | 265 cm | 265 cm | 265 cm | 265 cm | 265 cm |
| Fuel tank | 207 l | 207 l | 250 l | 250 l | 207 l | 207 l | 250 l | 250 l |
| Cab noise level | 73 dB | 73 dB | 73 dB | 73 dB | 71 dB | 73 dB | 73 dB | 73 dB |
| Solid cab | x | x | x | x | x | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock | friction lock | friction lock | friction lock | friction lock | friction lock |
| Air suspension seat | x | x | x | x | x | x | x | x |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. | opt. | opt. |
