Siirry sivupalkkiinSiirry alaosaanJohn Deere 6200-6400 SE




In the autumn of 1996, cheaper SE versions of the 6200 and 6400 models were introduced. However, they were not brought to Finland until a year later. The SE range featured a new 16+16-speed synchronized transmission without a quick shift and a hydraulic shuttle. The equipment and the cab were more basic. Instead of a closed hydraulic system, a gear pump producing 54 liters per minute was used. The lifting capacity was lower than the standard model. In the cab, the dashboard did not adjust with the steering wheel as it did in the standard model, and the heater was installed in the ceiling. The noise level was not specified but was higher than in the standard model. The shuttle control was located under the steering wheel on the left side. The cab was also available as a 10.5 cm lower LP version, which was not flat-floored.
The 6000-series SE models remained in production alongside the 6010 series for some time in 1998.
This is an automated translation. Please report any issues in the translation.
| Model | John Deere 6200 SE | John Deere 6400 SE |
|---|---|---|
| Manufacturer name | John Deere | John Deere |
| Imported to Finland | Yes | Yes |
| Years | 1996-98 | 1996-98 |
| Engine model | 4039 TL | 4045 TL |
| Cyl/Turbo/Intercooler | 4T | 4T |
| Displacement | 3920 cm³ | 4530 cm³ |
| Bore x stroke | 106,5×110 mm | 106,5×127 mm |
| Rated power | 84/2300 hp DIN/rpm | 100/2300 hp DIN/rpm |
| Torque | - | - |
| Gears | 16+16 | 16+16 |
| Synchronized gears | 16+16 | 16+16 |
| Reverser | hydr. | hydr. |
| Speeds in km/h | 2,4-40 | 2,4-40 |
| Hydr. flow l/min | 54 l/min | 54 l/min |
| Hydraulic pressure | 200 bar | 200 bar |
| Lift controls | elec. | elec. |
| Lift capacity | 3850 kg | 5150 kg |
| PTO speeds | 540/1000 | 540/1000 |
| Brakes | wet disc | wet disc |
| Steering | hydrost. | hydrost. |
| Turning circle m 4WD | 8.82 | 8.82 |
| Front tyres 4WD | 13.6R24 | 13.6R28 |
| Rear tyres 4WD | 16.9R34 | 16.9R38 |
| Weight 4WD | 3900 kg | 4100 kg |
| Height with cab | 264 cm | 269 cm |
| Length (2WD/4WD) | 414 cm | 421 cm |
| Wheelbase (2WD/4WD) | 240 cm | 240 cm |
| Fuel tank | 160 l | 160 l |
| Solid cab | x | x |
| Diff. lock | friction lock | friction lock |
