Siirry sivupalkkiinSiirry alaosaanJohn Deere 6110R-6155R




Here is the translation of the provided text into English:
In the smaller end of the John Deere 6R series, engines equipped with urea injection were introduced in the fall of 2015. Both the model numbers and the rated power increased by five steps. In the three larger models, there was significantly more additional power than before. The four-cylinder engines featured twin turbos, of which the high-pressure turbo operating at higher rpm had a variable geometry. The stated weights of the tractors were 600-1000 kg greater than previously, meaning that compared to the nearly 10-year-old 6430 Premium, the 6120R was 1350 kg heavier.
The basic transmission was the PowerQuad Plus with a four-speed powershift, which had a quick-shift adaptation when changing the range gear. The number of gears in four-cylinder models was 24+24 and in six-cylinder models 20+20. The quick shift automation was available in the AutoQuad Plus version, which was also available in a 50 km/h or 40 km/h Eco version. All models could also be equipped with the stepless AutoPowr transmission, which also included a pedal-drive mode. Starting from the 6145R, a DirectDrive dual-clutch transmission was offered, combining two mechanical gearboxes, each with its own clutch. One handled the even gears, and the other the odd gears. The load on the drivetrain controlled the shift to the next gear. The transmission had three ranges, each with eight quick shifts. The transmission could be operated automatically or manually. The transmission offered good efficiency but did not provide the jerk-free driving experience of a stepless transmission.
The load-sensing hydraulic output was standard at 80 liters, but in Finland, a 114-liter pump was standard. The lifting capacity in the 6110R and 6145R was increased. The noise level was reduced by one decibel to 71. The CommandArm console had been renewed.
At the beginning of 2019, the CommandPRO control lever was introduced, featuring 11 freely programmable buttons.
Let me know if you need any further assistance!
This is an automated translation. Please report any issues in the translation.
| Model | John Deere 6110R | John Deere 6120R | John Deere 6130R | John Deere 6135R | John Deere 6145R | John Deere 6155R |
|---|---|---|---|---|---|---|
| Manufacturer name | John Deere | John Deere | John Deere | John Deere | John Deere | John Deere |
| Imported to Finland | Yes | Yes | Yes | No | Yes | Yes |
| Years | 2016-22 | 2016-22 | 2016-22 | 2016-22 | 2016-22 | 2016-22 |
| Engine model | PSS | PSS | PSS | PSS | PVS | PVS |
| Cyl/Turbo/Intercooler | 4TI | 4TI | 4TI | 4TI | 6TI | 6TI |
| Displacement | 4530 cm³ | 4530 cm³ | 4530 cm³ | 4530 cm³ | 6788 cm³ | 6788 cm³ |
| Bore x stroke | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm |
| Rated power | - | - | - | - | - | - |
| Max power | - | - | - | - | - | - |
| Torque | - | - | - | - | - | - |
| Gears | 24+24 (stepless) | 24+24 (stepless) | 24+24 (stepless) | 24+24 (stepless) | 20+20 (stepless) | 20+20 (stepless) |
| Synchronized gears | 24+24 (stepless) | 24+24 (stepless) | 24+24 (stepless) | 24+24 (stepless) | 20+20 (stepless) | 20+20 (stepless) |
| Powershift gears | 4-speed (step) | 4-speed (step) | 4-speed (step) | 4-speed (step) | 4-speed (step) | 4-speed (step) |
| Reverser | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Speeds in km/h | 1,5-40/0,05-40 | 1,5-40/0,05-40 | 1,5-40/0,05-40 | 2,4-40/0,05-40 | 2,4-40/0,05-40 | 2,4-40/0,05-40 |
| Max. speed | 40 (50) km/h | 40 (50) km/h | 40 (50) km/h | 40 (50) km/h | 40 (50) km/h | 40 (50) km/h |
| Hydr. flow l/min | 80 (114) l/min | 80 (114) l/min | 80 (114) l/min | 80 (114) l/min | 80(114) l/min | 80 (114) l/min |
| Hydraulic pressure | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar | 200 bar |
| Lift controls | elec. | elec. | elec. | elec. | elec. | elec. |
| Lift capacity | 5300 kg | 5300 kg | 6000 kg | 6800 kg | 8100 kg | 8100 kg |
| PTO speeds | 540/750/1000 | 540/750/1000 | 540/750/1000 | 540/750/1000 | 540/750/1000 | 540/750/1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 10.88 | 10.94 | 10.94 | 11.28 | 12.32 | 12.62 |
| Front tyres 4WD | 420/85R24 | 420/85R24 | 420/85R24 | 380/70R28 | 420/85R28 | 420/85R28 |
| Rear tyres 4WD | 460/85R38 | 460/85R38 | 460/85R38 | 480/70R38 | 520/70R38 | 520/70R38 |
| Weight 4WD | 6000 kg | 6100 kg | 6200 kg | 6400 kg | 6900 kg | 7100 kg |
| Height with cab | 280 cm | 280 cm | 280 cm | 295 cm | 295 cm | 295 cm |
| Length (2WD/4WD) | 454 cm | 454 cm | 454 cm | 493 cm | 493 cm | 493 cm |
| Wheelbase (2WD/4WD) | 258 cm | 258 cm | 258 cm | 277 cm | 277 cm | 277 cm |
| Fuel tank | 195(225)+AB13 l | 195(225)+AB13 l | 195(225)+AB13 l | 305+AB16 l | 275(312)+AB16 l | 275(312)+AB16 l |
| Cab noise level | 71 dB | 71 dB | 71 dB | 71 dB | 71 dB | 71 dB |
| Solid cab | x | x | x | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock | friction lock | friction lock | friction lock |
| Air suspension seat | x | x | x | x | x | x |
| Air conditioning | x | x | x | x | x | x |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. |
