John Deere 5075M-5130M

Manufacturer
Models
John Deere 5075M, John Deere 5095M, John Deere 5105M, John Deere 5120M, John Deere 5130M
Years
2024-
Info

At the end of 2022, the Indian 5M series was introduced on other continents. However, the new models arrived in Europe only in the spring of 2024. The smallest model had a 2.9-liter 3-cylinder engine, and the others had a 4.5-liter engine. The lineup expanded upwards with the 5130M. The 4-cylinder engines featured 4-valve technology, wastegate turbocharging, and urea injection. The base versions had 16+16 gears, the PowrReverser version had no creeper gear, and the PowrReverser HiLo had a 2-speed creeper gear. As the name suggests, a hydraulic direction reverser was standard, and the clutch was oil-immersed. New were the PowrQuad Plus (16+16) with a 4-speed creeper gear and Powr8 (32+16) with an 8-speed creeper gear. The latter featured a 40 km/h Eco engine speed. The two newest had the SpeedMatch function for gear range shifting as well as range shifting via a button.

The mechanical lift had a lifting capacity of 3,236–4,109 kg. The electrical lift had a capacity of 3,704–4,326 kg, and in models equipped with a 4- or 8-speed creeper gear, 5,045–5,677 kg. The hydraulic pump was open and had an output of 70 or 73 l/min. The PTO clutch was electro-hydraulic. Models with a creeper gear also had a 1,000 rpm power take-off as standard. The wheelbase was 5 cm longer than before, but the turning radius was reduced to 8.2 meters. The 5M was also available without a cab. Air conditioning was standard, while optional extras included air suspension seat, LED work lights, ISOBUS, and a hydraulic trailer brake valve.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelJohn Deere 5075MJohn Deere 5095MJohn Deere 5105MJohn Deere 5120MJohn Deere 5130M
Manufacturer nameJohn DeereJohn DeereJohn DeereJohn DeereJohn Deere
Imported to FinlandYesYesYesYesYes
Years2024-2024-2024-2024-2024-
Engine modelPowerTech EPWSPWSPWSPWS
Cyl/Turbo/Intercooler3TI4TI4TI4TI4TI
Displacement2940 cm³4530 cm³4530 cm³4530 cm³4530 cm³
Bore x stroke106,5×110 mm106,5×127 mm106,5×127 mm106,5×127 mm106,5×127 mm
Rated power-----
Torque-----
Gears16+1616+16/32+1616+16/32+1616+16/32+1616+16/32+16
Synchronized gears16+1616+16/32+1616+16/32+1616+16/32+1616+16/32+16
Powershift gears-/hydr.-/hydr./4-step/8-step-/hydr./4-step/8-step-/hydr./4-step/8-step-/hydr./4-step/8-step
Reverserhydr.hydr.hydr.hydr.hydr.
Speeds in km/h2,0-422,0-422,0-422,0-422,0-42
Max. speed 40 km/h40 km/h40 km/h40 km/h40 km/h
Hydr. flow l/min70 l/min70/73 l/min70/73 l/min70/73 l/min73 l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar
Lift controlsmech. (elec.)mech. (elec.)mech. (elec.)mech. (elec.)mech. (elec.)
Lift capacity3236 (3704/4326) kg3236 (3704-5677) kg3236 (3704-5677) kg3236 (3704-5677) kg5045 (5677) kg
PTO speeds540/750 (1000)540/750 (1000)540/750 (1000)540/750 (1000)540/750/1000
Brakeswet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD8.28.28.28.28.2
Front tyres 4WD13.6R2413.6R2413.6R2413.6R2413.6R24
Rear tyres 4WD16.9R3416.9R3416.9R3416.9R3416.9R34
Weight 4WD4175 kg4175 (4400) kg4175 (4400) kg4175 (4400) kg4400 kg
Height with cab264 cm264 cm264 cm264 cm264 cm
Wheelbase (2WD/4WD)235 cm235 cm235 cm235 cm235 cm
Fuel tank191 l159+AB12 l159+AB12 l159+AB12 l159+AB12 l
Cab noise level77 dB77 dB77 dB77 dB77 dB
Solid cabxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lock
Air conditioningxxxxx
Creeper gearopt.opt.opt.opt.opt.
Max power-----
