Fendt Farmer 310 LS – 312 LS
Manufacturer
Models
Fendt Farmer 310 LS, Fendt Farmer 311 LS, Fendt Farmer 312 LS
Years
1987-90
Info
The 1988 updates for the large Farmers models were small and minor, as some of the improvements were already standard on the larger models. The noise level in the cabin was reduced to 76.5-77.5 decibels. The power of the 310 model increased by 3 horsepower to 95. The turning radius was slightly reduced by tilting the kingpin 5 degrees backward. However, the most significant change was the expansion of the lineup with the addition of the 312 model, which had 115 horsepower.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Fendt Farmer 310 LS | Fendt Farmer 311 LS | Fendt Farmer 312 LS |
|---|---|---|---|
| Options | |||
| Manufacturer name | Fendt Farmer | Fendt Farmer | Fendt Farmer |
| Imported to Finland | Yes | Yes | Yes |
| Years | 1987-90 | 1987-90 | 1987-90 |
| First year sold | 1987 | 1987 | 1987 |
| Last year sold | 1990 | 1990 | 1990 |
| Engine model | MWM TD226-4 | MWM D226-6 | MWM D226-6 |
| Cyl/Turbo/Intercooler | 4T | 6 | 6 |
| Displacement | 4154 cm³ | 6240 cm³ | 6240 cm³ |
| Bore x stroke | 105×120 mm | 105×120 mm | 105×120 mm |
| Rated power hp/rpm DIN | 95/2350 | 100/2300 | 115/2400 |
| Rated power | 95 | 100 | 115 |
| Rated speed | 2350 | 2300 | 2400 |
| Torque Nm/rpm DIN | 358/1500 | 384/1500 | 413/1600 |
| Gears | 21+6 | 21+6 | 21+6 |
| Synchronized gears | 21+6 | 21+6 | 21+6 |
| Powershift gears | mech. 3-step | mech. 3-step | mech. 3-step |
| Speeds in km/h | 1,3-40 | 1,3-40 | 1,3-40 |
| Max. speed | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 40 l/min | 40 l/min | 44 l/min |
| Hydraulic pressure | 180 bar | 180 bar | 190 bar |
| Lift controls | elec. | elec. | elec. |
| Lift capacity | 4750 kg | 4750 kg | 4750 kg |
| PTO speeds | 540/750/1000 | 540/750/1000 | 540/750/1000 |
| Brakes | dry disc | dry disc | dry disc |
| Steering | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 9.2 | 10.6 | 10.6 |
| Front tyres 4WD | 14.9R24 | 14.9R26 | 14.9R28 |
| Rear tyres 4WD | 16.9R38 | 18.4R38 | 18.4R38 |
| Weight 4WD | 4450 kg | 4690 kg | 5050 kg |
| Height with cab | 272 cm | 275 cm | 275 cm |
| Length (2WD/4WD) | 411 cm | 437 cm | 437 cm |
| Wheelbase (2WD/4WD) | 239/232 cm | 259 cm | 259 cm |
| Fuel tank | 135 l | 135/160 l | 160 l |
| Cab noise level | 76.5 dB | 77.5 dB | 77 dB |
| Solid cab | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock |
| Creeper gear | opt. | opt. | opt. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
