Welcome to the beta version of Koneviesti's new Konedata service! The service offers technical data for over 8000 tractors and combines. We are actively developing the service, so we appreciate your feedback.

Give feedback

Model	Fendt Farmer 250 S	Fendt Farmer 260 S	Fendt Farmer 280 S
Manufacturer name	Fendt Farmer	Fendt Farmer	Fendt Farmer
Imported to Finland	No	No	No
Years	1996-2003	1996-2003	1996-2003
Engine model	KHD F3L912	KHD F3L913	KHD F4L913
Cyl/Turbo/Intercooler	3	3	4
Displacement	2826 cm³	3064 cm³	4086 cm³
Bore x stroke	100×120 mm	102×125 mm	102×125 mm
Rated power	50/2300 hp DIN/rpm	60/2400 hp DIN/rpm	80/2300 hp DIN/rpm
Torque	-	-	-
Gears	21+6	21+6	21+6
Synchronized gears	21+6	21+6	21+6
Powershift gears	mech.	mech.	mech.
Reverser	opt.	opt.	opt.
Speeds in km/h	1,4-40,0	1,4-40,0	1,4-40,0
Hydr. flow l/min	39 l/min	41 l/min	41 l/min
Lift controls	elec.	elec.	elec.
Lift capacity	2790 kg	2790 kg	2790 kg
PTO speeds	540/750/1000	540/750/1000	540/750/1000
Brakes	dry disc	dry disc	dry disc
Steering	hydrost.	hydrost.	hydrost.
Turning circle m 2WD	6.2	6.2	-
Turning circle m 4WD	6.6	6.6	7.2
Front tyres 2WD	7,50-18	7,50-18	-
Front tyres 4WD	11.2R20	11.2R20	12.4R20
Rear tyres 2WD	14,9R30	16,9R28	-
Rear tyres 4WD	14.9R30	16.9R28	16.9R30
Weight 2WD	2500 kg	2520 kg	-
Weight 4WD	2750 kg	2770 kg	2970 kg
Height with cab	230 cm	232 cm	235 cm
Length (2WD/4WD)	354 cm	354 cm	364 cm
Wheelbase (2WD/4WD)	205 cm	205 cm	218 cm
Fuel tank	60 l	60 l	60 l
Cab noise level	82 dB	82 dB	82 dB
Solid cab	x	x	x
Diff. lock	friction lock	friction lock	friction lock
Creeper gear	opt.	opt.	opt.
