Fendt Farmer 207-211 Vario

15Fendt200
15Fendt200ohjaamo
15Fendt200tehot
15Fendt200
15Fendt200ohjaamo
15Fendt200tehot
Manufacturer
Models
Fendt Farmer 207 Vario, Fendt Farmer 208 Vario, Fendt Farmer 209 Vario, Fendt Farmer 210 Vario, Fendt Farmer 211 Vario
Years
2010-2017
Info

At Agritechnica in autumn 2009, a smaller version of the 200-series Fendt Vario was introduced, equipped with the company's own 3.3-liter Agco Power engines. The engines featured common rail injection and exhaust gas recirculation. Later tightening of emission standards was managed similarly to Valtra by tweaking the nominal power ratings model-specifically to 38, 41, 44, 46, and 49 hp. The Vario transmission was the same ML 75 as in the 300 series and did not have separate field and road ranges. A speed of 40 km/h was achieved at 1700 rpm. There were two cruise control memories. The TMS system, which adjusts engine speed according to load, was an optional extra. The lifting device was electrically operated and offered a lifting capacity of 4200 kg. As an option, hydraulics could be equipped with a dual pump producing 76 l/min.

Unlike the larger models, the electrical system was implemented without bus technology. Standard equipment included, among other things, a passenger seat and the disengagement of four-wheel drive and differential locks based on speed, and from the 2015 model year onwards, also an air suspension seat. Optional extras included manual or automatic air conditioning and cab suspension.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelFendt Farmer 207 VarioFendt Farmer 208 VarioFendt Farmer 209 VarioFendt Farmer 210 VarioFendt Farmer 211 Vario
Options
Manufacturer nameFendt FarmerFendt FarmerFendt FarmerFendt FarmerFendt Farmer
Imported to FinlandYesYesYesYesYes
Years2010-172010-172010-172010-172010-17
First year sold20102010201020102010
Last year sold20172017201720172017
Engine model33 CTA33 CTA33 CTA33 CTA33 CTA
Cyl/Turbo/Intercooler3TI3TI3TI3TI3TI
Displacement3300 cm³3300 cm³3300 cm³3300 cm³3300 cm³
Bore x stroke108×120 mm108×120 mm108×120 mm108×120 mm108×120 mm
Rated power hp/rpm DIN60/210070/210080/210090/2100100/2100
Rated power60708090100
Rated speed21002100210021002100
Max power hp/rpm DIN70/190080/190090/1900100/1900110/1900
Max power708090100110
Max speed19001900190019001900
Rated power hp/rpm ISO71/210082/210091/210099/2100101/2100
Max power hp/rpm ISO75/190085/190095/1900105/1900115/1900
Torque Nm/rpm DIN295/1600337/1600373/1600408/1600458/1600
Gearssteplesssteplesssteplesssteplessstepless
Synchronized gearssteplesssteplesssteplesssteplessstepless
Powershift gearssteplesssteplesssteplesssteplessstepless
Reverserhydr.hydr.hydr.hydr.hydr.
Speeds in km/h0,02-400,02-400,02-400,02-400,02-40
Max. speed 40 km/h40 km/h40 km/h40 km/h40 km/h
Hydr. flow l/min48 (76) l/min48 (76) l/min48 (76) l/min48 (76) l/min48 (76) l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar
Lift controlselec.elec.elec.elec.elec.
Lift capacity4204 kg4204 kg4204 kg4204 kg4204 kg
PTO speeds540/750/1000540/750/1000540/750/1000540/750/1000540/750/1000
Brakeswet piston brakeswet piston brakeswet piston brakeswet piston brakeswet piston brakes
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD7.967.967.967.967.96
Front tyres 4WD320/70R24320/70R24380/70R24380/70R24445/65R24
Rear tyres 4WD420/85R30480/70R30420/70R34420/70R34540/65R34
Weight 4WD3750 kg3790 kg3870 kg3870 kg3930 kg
Height with cab248 cm248 cm253 cm253 cm253 cm
Length (2WD/4WD)407 cm407 cm407 cm407 cm407 cm
Wheelbase (2WD/4WD)229 cm229 cm229 cm229 cm229 cm
Fuel tank125 l125 l125 l125 l125 l
Cab noise level76 dB76 dB76 dB76 dB76 dB
Solid cabxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lock
Autom. differential locksxxxxx
Air suspension seat2014-2014-2014-2014-2014-
Creeper gearxxxxx
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
