Fendt Farmer 102 S – 108 S
Manufacturer
Models
Fendt Farmer 102 S, Fendt Farmer 103 S, Fendt Farmer 104 S, Fendt Farmer 105 S, Fendt Farmer 106 S, Fendt Farmer 108 S
Years
1976-79
Info
In 1976, new MWM engines were introduced. The displacement of the 3-cylinder engines was now 3.1 liters and the 4-cylinder engines 4.15 liters. The 105 and 106 had already received a new engine at the beginning of 1975. All models were now equipped with a turbo clutch. The tires were larger than before. The fuel tanks also increased in size. The Farmers were available with a roll bar, a basic weather shield, and two different types of cabins. Regardless of the cabin, the gear levers were located in the center and the pedals were of the model that is pressed through the floor.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Fendt Farmer 102 S | Fendt Farmer 103 S | Fendt Farmer 104 S | Fendt Farmer 105 S | Fendt Farmer 106 S | Fendt Farmer 108 S |
|---|---|---|---|---|---|---|
| Manufacturer name | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer |
| Imported to Finland | No | No | No | No | No | No |
| Years | 1976-79 | 1976-79 | 1976-79 | 1975-79 | 1975-79 | 1975-79 |
| Engine model | MWM D226-3 | MWM D226-3 | MWM D226-3 | MWM D226-4 | MWM D226-4 | MWM D226-4 |
| Cyl/Turbo/Intercooler | 3 | 3 | 3 | 4 | 4 | 4 |
| Displacement | 3116 cm³ | 3116 cm³ | 3116 cm³ | 4154 cm³ | 4154 cm³ | 4154 cm³ |
| Bore x stroke | 105×120 mm | 105×120 mm | 105×120 mm | 105×120 mm | 105×120 mm | 105×120 mm |
| Rated power | 45/2175 hp DIN/rpm | 50/2175 hp DIN/rpm | 55/2300 hp DIN/rpm | 60/2175 hp DIN/rpm | 65/2175 hp DIN/rpm | 75/2300 hp DIN/rpm |
| Gears | 13+4 | 13+4 | 13+4 | 13+4 | 13+4 | 13+4 |
| Synchronized gears | 13+4 | 13+4 | 13+4 | 13+4 | 13+4 | 13+4 |
| Powershift gears | mech. | mech. | mech. | mech. | mech. | mech. |
| Speeds in km/h | 1,2-30,0 | 1,3-30,0 | 1,3-30,0 | 1,3-30,0 | 1,3-30,0 | 1,3-30,0 |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 2000 kg | 2000 kg | 2000 kg | 2580 kg | 2580 kg | 3280 kg |
| PTO speeds | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Brakes | dry disc | dry disc | dry disc | dry disc | dry disc | dry disc |
| Steering | mech. | mech./hydr. | mech./hydr. | hydrost. | hydrost. | hydrost. |
| Turning circle m 2WD | 7.6 | 7.6 | 7.6 | 7.6 | 8 | 8 |
| Turning circle m 4WD | 8.8 | 8.8 | 8.8 | 9.3 | 9.2 | 9.2 |
| Front tyres 2WD | 6,00-16 | 6,00-16 | 6,50-20 | 6,50-20 | 7,50-18 | 7,50-18 |
| Front tyres 4WD | 7.50-18 | 7.50-18 | 10.5-20 | 10.5-20 | 11.2-24 | 11.2-24 |
| Rear tyres 2WD | 12,4-32 | 12,4-36 | 12,4-36 | 13,6-36 | 13,6-38 | 13,6-38 |
| Rear tyres 4WD | 12.4-32 | 12.4-36 | 12.4-36 | 13.6-36 | 13.6-38 | 13.6-38 |
| Weight 2WD | 2420 kg | 2460 kg | 2500 kg | 2760 kg | 3055 kg | 3120 kg |
| Weight 4WD | 2730 kg | 2780 kg | 2790 kg | 3070 kg | 3470 kg | 3500 kg |
| Height with cab | 232 cm | 237 cm | 241 cm | 240 cm | 250 cm | 245 cm |
| Length (2WD/4WD) | 367 cm | 367 cm | 367 cm | 382 cm | 382 cm | 382 cm |
| Wheelbase (2WD/4WD) | 208/211 cm | 208/211 cm | 212/211 cm | 225/219 cm | 225/219 cm | 225/223 cm |
| Fuel tank | 73 l | 73 l | 73 l | 93 l | 93 l | 93 l |
| Solid cab | opt. | opt. | opt. | opt. | opt. | opt. |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. |
