Fendt Farmer 1 E – 5 S
Fendt overhauled its styling in the spring of 1968. The old-fashioned rounded lines were replaced by a contemporary angular design that remained largely unchanged into the 1990s.
The Farmer series, which had debuted in 1958, retained most of its original technology. The three-cylinder engines—except for the 2 D—were now water-cooled MWM units, just like the earlier four-cylinder models. The S models featured an additional gear, allowing them to reach 30 km/h on the road, and they were also equipped with a torque converter.
The four-wheel-drive versions had hydrostatic steering, and their front axle was manufactured by ZF. Sales of the four-wheel-drive models were still modest.
In 1970 the largest model in the range became the 5 S, with an output of 65 hp.
This is an automated translation. Please report any issues in the translation.
| Model | Fendt Farmer 1 E | Fendt Farmer 1 D | Fendt Farmer 2 D | Fendt Farmer 2 DE | Fendt Farmer 2 E | Fendt Farmer 2 S | Fendt Farmer 3 S | Fendt Farmer 4 S | Fendt Farmer 5 S |
|---|---|---|---|---|---|---|---|---|---|
| Options | |||||||||
| Manufacturer name | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer | Fendt Farmer |
| Imported to Finland | No | No | No | No | No | No | No | No | No |
| Years | 1967-71 | 1971-73 | 1968-71 | 1968-71 | 1968-70 | 1968-72 | 1968-72 | 1968-72 | 1970-72 |
| First year sold | 1967 | 1971 | 1968 | 1968 | 1968 | 1968 | 1968 | 1968 | 1970 |
| Last year sold | 1971 | 1973 | 1971 | 1971 | 1970 | 1972 | 1972 | 1972 | 1972 |
| Engine model | MWM D325-2 | MWM D325-3 | MWM KD110.5D | MWM D208-3 | MWM D208-3 | MWM D208-3 | MWM D208-4 | MWM D208-4 | MWM D208-4 |
| Cyl/Turbo/Intercooler | 2 | 3 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Displacement | 1700 cm³ | 2550 cm³ | 2010 cm³ | 2233 cm³ | 2233 cm³ | 2233 cm³ | 2976 cm³ | 2976 cm³ | 2976 cm³ |
| Bore x stroke | 95×120 mm | 95×120 mm | - | 95×105 mm | 95×105 mm | 95×105 mm | 95×105 mm | 95×105 mm | 95×105 mm |
| Rated power hp/rpm DIN | 30/2275 | 34/2100 | 32/? | 35/2100 | 40/2100 | 42/2380 | 45/2125 | 55/2400 | 65/2400 |
| Rated power | 30 | 34 | 32 | 35 | 40 | 42 | 45 | 55 | 65 |
| Rated speed | 2275 | 2100 | - | 2100 | 2100 | 2380 | 2125 | 2400 | 2400 |
| Gears | 6+2 | 12+4 | 8+4 | 8+4 | 8+4 | 13+4 | 13+4 | 13+4 | 13+4 |
| Synchronized gears | - | - | partial | partial | partial | 13+4 | 13+4 | 13+4 | 13+4 |
| Powershift gears | opt. | mech. | opt. | opt. | opt. | mech. | mech. | mech. | mech. |
| Speeds in km/h | 1,8-20,0 | 1,3-25,0 | 1,2-20,0 | 1,2-20,0 | 1,2-20,0 | 1,3-30,0 | 1,3-30,0 | 1,3-30,0 | 1,3-30,0 |
| Max. speed | - | - | 20/30 km/h | 20/30 km/h | 20/30 km/h | - | - | - | - |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 1500 kg | 1500 kg | 1500 kg | 1500 kg | - | 2000 kg | 2000 kg | 2000 kg | 2000 kg |
| PTO speeds | 540 | 540 | 540 | 540 | 540 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Brakes | shoe brakes | shoe brakes | shoe brakes | shoe brakes | shoe brakes | shoe brakes | shoe brakes | shoe brakes | shoe brakes |
| Steering | mech. | mech. | mech. | mech. | mech. | mech./hydr. | mech./hydr. | mech./hydr. | mech./hydr. |
| Turning circle m 2WD | 6.6 | - | 7 | 7 | 7 | 7.6 | 8 | 8 | 8 |
| Turning circle m 4WD | - | - | - | - | - | 8.8 | - | - | - |
| Front tyres 2WD | 5,00-16 | 5,50-16 | 5,50-16 | 5,50-16 | 6,00-16 | 6,00-16 | 6,50-20 | 6,50-20 | 6,50-20 |
| Front tyres 4WD | - | - | - | - | - | 10.5-18 | 10.5-18 | 10.5-20 | 9.5-24 |
| Rear tyres 2WD | 9,5-30 | 11,2-28 | 9,5-32 | 9,5-32 | 9,5-36 | 9,5-36 | 12,4-36 | 13,6-36 | 13,6-36 |
| Rear tyres 4WD | - | - | - | - | - | 12.4-32 | 12.4-36 | 13.6-36 | 13.6-36 |
| Weight 2WD | 1610 kg | 1775 kg | 1820 kg | 1820 kg | 1960 kg | 2225 kg | 2420 kg | 2460 kg | 3020 kg |
| Weight 4WD | - | - | - | - | - | 2510 kg | 2655 kg | 2695 kg | 3395 kg |
| Height with cab | 220 cm | 232 cm | 215 cm | 215 cm | 225 cm | 229 cm | 237 cm | 240 cm | 245 cm |
| Length (2WD/4WD) | 318 cm | 331 cm | 326 cm | 326 cm | 326 cm | 363 cm | 381 cm | 381 cm | 382 cm |
| Wheelbase (2WD/4WD) | 187 cm | 199 cm | 197 cm | 197 cm | 197 cm | 209/206 cm | 225/219 cm | 225/219 cm | 225/219 cm |
| Fuel tank | 31 l | - | - | - | - | - | 83 l | 83 l | 83 l |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. | opt. | opt. | opt. |
