Fendt 1149-1165 MT
Manufacturer
Models
Fendt 1149 MT, Fendt 1154 MT, Fendt 1159 MT, Fendt 1165 MT
Years
2017-2020
Info
Agritechnica 2017 saw Fendt unveil its first tracked tractors, which replaced the Challengers on the European market. Production took place in the USA. The larger 1100 MT series was derived from the Challenger 800MT with considerably fewer modifications. The cab received only control‐system updates, and the powertrain was Caterpillar’s 16‐speed powershift. The engine was Agco Power’s 16.8-liter V12, delivering its maximum output at 1,500–2,100 rpm. The transmission automation could be set to prioritize either constant speed or maximum power. The hydraulic variable-displacement pump produced either 224 or 321 l/min, and the cab noise level was 67 dB.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Fendt 1149 MT | Fendt 1154 MT | Fendt 1159 MT | Fendt 1165 MT |
|---|---|---|---|---|
| Options | ||||
| Manufacturer name | Fendt | Fendt | Fendt | Fendt |
| Imported to Finland | Yes | Yes | Yes | Yes |
| Years | 2017-20 | 2017-20 | 2017-20 | 2017-20 |
| First year sold | 2017 | 2017 | 2017 | 2017 |
| Last year sold | 2020 | 2020 | 2020 | 2020 |
| Engine model | Agco AP168 | Agco AP168 | Agco AP168 | Agco AP168 |
| Cyl/Turbo/Intercooler | V12TI | V12TI | V12TI | V12TI |
| Displacement | 14736 cm³ | 14736 cm³ | 14736 cm³ | 14736 cm³ |
| Bore x stroke | 111×145 mm | 111×145 mm | 111×145 mm | 111×145 mm |
| Rated power hp/rpm ISO | 457/2100 | 496/2100 | 548/2100 | 598/2100 |
| Rated power | - | - | - | - |
| Rated speed | - | - | - | - |
| Max power hp/rpm ISO | 492/1900 | 536/1900 | 592/1900 | 646/1900 |
| Max power | - | - | - | - |
| Max speed | - | - | - | - |
| Torque Nm/rpm DIN | 2170/1500 | 2360/1500 | 2600/1500 | 2840/1500 |
| Gears | 16+4 | 16+4 | 16+4 | 16+4 |
| Synchronized gears | powershift | powershift | powershift | powershift |
| Powershift gears | powershift | powershift | powershift | powershift |
| Reverser | hydr. | hydr. | hydr. | hydr. |
| Max. speed | 40 km/h | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 224 (321) l/min | 224 (321) l/min | 224 (321) l/min | 224 (321) l/min |
| Hydraulic pressure | 200 bar | 200 bar | 200 bar | 200 bar |
| Lift controls | elec. | elec. | elec. | elec. |
| Lift capacity | 14000 kg | 14000 kg | 14000 kg | 14000 kg |
| PTO speeds | 1000 | 1000 | 1000 | 1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. |
| Rear tyres 4WD | 699 mm | 699 mm | 699 mm | 699 mm |
| Weight 4WD | 19365 kg | 19365 kg | 19365 kg | 19365 kg |
| Height with cab | 346 cm | 346 cm | 346 cm | 346 cm |
| Length (2WD/4WD) | 676 cm | 676 cm | 676 cm | 676 cm |
| Wheelbase (2WD/4WD) | 300 cm | 300 cm | 300 cm | 300 cm |
| Fuel tank | 1000+AB106 l | 1000+AB106 l | 1000+AB106 l | 1000+AB106 l |
| Cab noise level | 67 dB | 67 dB | 67 dB | 67 dB |
| Solid cab | x | x | x | x |
| Air suspension seat | x | x | x | x |
| Air conditioning | x | x | x | x |
| Trip computer | x | x | x | x |
| Creeper gear | x | x | x | x |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
