Eicher ED 110/II - ED 215/16

Manufacturer
Models
Eicher ED 110/II, Eicher ED 110/8, Eicher ED 115/8, Eicher ED 210/10, Eicher ED 215/16
Years
1958-60
Info

In 1958, the first models of the new predator series were introduced, as well as intermediate models ED 110…ED 215, whose design already closely resembled the next lineup. The model designations referred to the number of cylinders, cylinder diameter, and ZF transmission model. The ED 110/II was equipped with a Hurth 6+1 transmission instead of ZF. The ZF transmissions featured a new dog clutch. There was also a four-wheel drive version of the ED 215, with 10-24 tires on the front and rear.

The hood shape of the new models was onion-shaped. A new optional feature was front PTO. The most successful model in the lineup was the ED 110/II, the successor to the EKL 15. On some export markets, the four smallest models were sold under the model names E 17, E 20, E 24, and E 35.

Technical data
ModelEicher ED 110/IIEicher ED 110/8Eicher ED 115/8Eicher ED 210/10Eicher ED 215/16
Options
Imported to FinlandNoNoNoNoNo
Years1958-601958-591958-591958-601958-60
First year sold19581958195819581958
Last year sold19601959195919601960
Engine modelED 1bED 1dED 1dED 2bED 2d
Cyl/Turbo/Intercooler11122
Displacement1425 cm³1425 cm³1557 cm³2851 cm³3114 cm³
Bore x stroke110×150 mm110×150 mm115×150 mm110×150 mm115×150 mm
Rated power hp/rpm DIN16/150019/150022/165033/150033/1500
Rated power1619223333
Rated speed15001500165015001500
Torque Nm/rpm DIN78/100098/1100117/1150166/1100196/1025
Gears6+16+16+15+25+2
Max. speed 20,0 km/h18,0 km/h20,0 km/h20,0 km/h18,0/24,0 km/h
Lift controlsmech.mech.mech.mech.mech.
Lift capacity625 kg625 kg625 kg--
PTO speeds540540540540540
Brakesdrum brakesdrum brakesdrum brakesdrum brakesdrum brakes
Steeringmech.mech.mech.mech.mech.
Front tyres 2WD4.50-165.50-165.50-166.00-166.00-20
Rear tyres 2WD11.2/10-2811.2/10-2811.2/10-2812.4/11-2814.9/13-30
Weight 2WD(1280) kg(1420) kg(1420) kg(2170) kg(2430) kg
Height with cab(157) cm(166) cm(166) cm(171) cm(188) cm
Length (2WD/4WD)252 cm252 cm252 cm320 cm337 cm
Wheelbase (2WD/4WD)164 cm180 cm180 cm197 cm211 cm
Creeper gearopt.opt.opt.opt.opt.
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
