The Kharkov Tractor Factory had mainly produced crawler tractors, but in 1950, production began there of a small 12 hp wheeled tractor. The engine of the HTZ-7 was a 2-cylinder gasoline engine. The transmission was a 4+4 equipped with a direction reverser. Also exceptional for this size class was a hydraulic lifting device. The HTZ-7 was a so-called "reversible tractor": the seat could be moved to the other side of the vertically positioned steering shaft by loosening two bolts, and the steering wheel could simultaneously be attached to another pin on the steering shaft. The tractor was started with a crank. In addition to magneto ignition, the only electrical equipment—namely the lights—received power from a dynamo. During a period of six years, about 48,000 units of the HTZ-7 were manufactured. Only a few were imported to Finland; however, its diesel-powered successor, the DT-14, became well known here as well.
This is an automated translation. Please report any issues in the translation.

**Translation:**

The Kharkov Tractor Factory had mainly produced crawler tractors, but in 1950, production began there of a small 12 hp wheeled tractor. The engine of the HTZ-7 was a 2-cylinder gasoline engine. The transmission was a 4+4 equipped with a direction reverser. Also exceptional for this size class was a hydraulic lifting device. The HTZ-7 was a so-called "reversible tractor": the seat could be moved to the other side of the vertically positioned steering shaft by loosening two bolts, and the steering wheel could simultaneously be attached to another pin on the steering shaft. The tractor was started with a crank. In addition to magneto ignition, the only electrical equipment—namely the lights—received power from a dynamo. During a period of six years, about 48,000 units of the HTZ-7 were manufactured. Only a few were imported to Finland; however, its diesel-powered successor, the DT-14, became well known here as well.

This is an automated translation. Please report any issues in the translation.

Belarus HTZ-7

Malli

Hinta (sis. alv)

Series specifier

Manufacturer name

Model specifier

Imported to Finland

Years

First year sold

Last year sold

Engine model

Cyl/Turbo/Intercooler

Displacement

Bore x stroke

Power

Power speed

Rated power hp/rpm DIN

Rated power

Rated speed

Max power hp/rpm DIN

Max power

Max speed

Rated power hp/rpm ISO

Max power hp/rpm ISO

Max power hp/rpm

Rated power hp/rpm ECE

Max power	hp/rpm ECE

Rated power hp/rpm SAE

Rated power hp/rpm PTO

Rated power hp/rpm engine pulley

Rated power hp/rpm

Torque Nm/rpm

Torque Nm/rpm ECE

Torque Nm/rpm ISO

Torque Nm/rpm SAE

Torque Nm/rpm DIN

Gears

Creeper speeds

Synchronized gears

Powershift gears

Reverser

Speeds in km/h

Max. speed

Hydr. flow l/min

Hydraulic pressure

Lift controls

Lift capacity

PTO speeds

Brakes

Steering

Turning circle m 2WD

Turning circle m 4WD

Front tyres 2WD

Front tyres 4WD

Rear tyres 2WD

Rear tyres 4WD

Weight 2WD

Weight 4WD

Height with cab

Length (2WD/4WD)

Wheelbase (2WD/4WD)

Fuel tank

Cab noise level

Solid cab

Diff. lock

Autom. differential locks

Air suspension seat

Air conditioning

Trip computer

Creeper gear

Sylinterien lukumäärä

Iskutilavuus

Iskusuhde

Suurin vääntömomentti, Nm

Suurin vääntömomentti, r/min

Vääntömomentin nousu

Polttonesteen kulutus suurimman tehon pisteessä

Kytkimen tyyppi

Ajovoimanotto

Nopeus eteenpäin moottorin nimellisnopeudella, pienin

Nopeus eteenpäin moottorin nimellisnopeudella, suurin

Jarrut

Hydrauliikan suurin paine

Hydrauliikan suurin tuotto

Nostolaitehydrauliikan hallinta

Ulkopuolinen hydrauliikka, venttiililohkoja

1-toimisia

2-toimisia

Nostovoima (kN=100 kg)

Hydrauliikan tyyppi

Kääntöympyrän halkaisija ilman ohjausjarrua

Eturenkaat

Takarenkaat

Kokonaismassa säiliöt täynnä vakiovarustein

Etuakselipaino

Taka-akselipaino

Suurin korkeus (ohjaamon ylimpään kohtaan)

HTZ-7

Etusivu

Ajoneuvot ja ympäristö

Huolto ja tekniikka

Lukijan idea

Maarakennus

Maatalous

Osastot

Metsä

Pääkirjoitus

Uutiset

Weteraani

Yritykset ja tapahtumat

Lukijan kuvat

Koneviesti

Lehdet

Konedata

Palvelut

Tilaa Koneviesti

Asiakaspalvelu

Jätä ilmoitus

Tilaa uutiskirje

Lähetä uutisvinkki

Lähetä palautetta

Lähetä oikaisupyyntö

Toimituksen yhteystiedot

Mediamyynnin yhteystiedot

Ota yhteyttä

Subscribe

Paywall

Send feedback

Welcome to the beta version of Koneviesti's new Konedata service! The service offers technical data for over 8000 tractors and combines. We are actively developing the service, so we appreciate your feedback.

Give feedback

Model	Belarus HTZ-7
Options
Manufacturer name	Belarus
Imported to Finland	Yes
Years	1950-56
First year sold	1950
Last year sold	1956
Engine model	G7
Cyl/Turbo/Intercooler	2
Displacement	1320 cm³
Bore x stroke	82×125 mm
Rated power hp/rpm DIN	12/1600
Rated power	12
Rated speed	1600
Torque Nm/rpm DIN	64/1000
Gears	4+4 (5+4)
Reverser	x
Speeds in km/h	4,1-12,7
Lift controls	mech.
Lift capacity	450 kg
PTO speeds	545
Brakes	vannej.
Steering	mech.
Front tyres 2WD	4.00-16
Rear tyres 2WD	8-32
Weight 2WD	(1300) kg
Height with cab	(111-126) cm
Length (2WD/4WD)	244-255 cm
Wheelbase (2WD/4WD)	143-165 cm
Fuel tank	40 l
