Belarus 1523.5-2022.6

Manufacturer
Models
Belarus 1523.5, Belarus 1523.6, Belarus 1523.6, Belarus 2022.5, Belarus 2022.6
Years
2013-
Info

Belarus introduced models meeting different emission requirements as regulations tightened, and all the old versions remained in the lineup for markets that were satisfied with them. The novelty of the 4-series was the common rail injection system, which allowed meeting Stage IIIA requirements. The 5-series introduced in 2013 featured urea injection, achieving Stage IIIb/Tier 4i levels. In 2015, the 6-series came out, equipped with an oxidation catalyst and emissions compliant with Stage IV/Tier 4. It is noteworthy that these requirements were met with their own engines, although at the lower emission levels, engines purchased externally were initially needed.

The 150-210 horsepower Belarus tractors did not gain much popularity, at least in Europe. Their technology was quite simple for their size class. The transmission was 16+8 or 24+12 without creep gears. The lifting capacity was 6.5 tons, and the power lift was standard.

In autumn 2019, the 1523.6 was introduced with a new appearance.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelBelarus 1523.5Belarus 1523.6Belarus 1523.6Belarus 2022.5Belarus 2022.6
Manufacturer nameBelarusBelarusBelarusBelarusBelarus
Imported to FinlandYesNoNoYesNo
Years2013-2015-192019-2013-2015-
Engine modelD-260.1S3BD-260.1S4D-260.1S4D-260.4S3BD-260.4S3B
Cyl/Turbo/Intercooler6TI6TI6TI6TI6TI
Displacement7120 cm³7120 cm³7120 cm³7120 cm³7120 cm³
Bore x stroke110×125 mm110×125 mm110×125 mm110×125 mm110×125 mm
Rated power150/2100 hp DIN/rpm153/2100 hp DIN/rpm153/2100 hp DIN/rpm212/2100 hp DIN/rpm212/2100 hp DIN/rpm
Torque-----
Gears16+8/24+1216+8/24+1216+8/24+1224+1224+12
Synchronized gears16+8/24+1216+8/24+1216+8/24+1224+1224+12
Speeds in km/h1,7-32,41,7-32,41,7-32,81,9-39,71,9-39,7
Hydr. flow l/min55 l/min55 l/min55 l/min55 l/min55 l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar
Lift controlselec.elec.elec.elec.elec.
Lift capacity6500 kg6500 kg6500 kg6500 kg6500 kg
PTO speeds540/750/ 1000/1300540/750/ 1000/1300540/750/ 1000/1300540/750/ 1000/1300540/750/ 1000/1300
Brakeswet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD11111111.611.6
Front tyres 4WD420/70R24420/70R24420/70R24420/70R24420/70R24
Rear tyres 4WD520/70R38520/70R38520/70R38580/70R42580/70R42
Weight 4WD6400 kg6500 kg6780 kg7400 kg7400 kg
Height with cab300 cm300 cm300 cm312 cm312 cm
Length (2WD/4WD)471 cm471 cm507 cm523 cm523 cm
Wheelbase (2WD/4WD)276 cm276 cm276 cm292 cm292 cm
Fuel tank190 l190 l200 l300 l300 l
Cab noise level83 dB83 dB83 dB83 dB83 dB
Solid cabxxxxx
Diff. lockdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogsdifferential lock with cogs
Autom. differential locksxxxxx
Air conditioningxxxxx
Creeper gearopt.----
