Valtra A75-A135

Manufacturer
Models
Valtra A75, Valtra A85, Valtra A95, Valtra A105, Valtra A115, Valtra A125, Valtra A135
Years
2021-
Info

The Valtra A-series, corresponding to MF's Global Series, was renewed at the beginning of 2021. The engines now complied with the Stage V emission standard, meaning that in addition to urea injection and an oxidation catalyst, a particulate filter was required, but no exhaust gas recirculation. The four largest models had 4-cylinder engines with 5 hp more power than before and noticeably more torque in the A105 and A115 models. The service interval was now 600 hours.

The base model was now called GL. Its transmission was 12+12 without a creeper gear, or as a new feature in the 3-cylinder models, 24+24 with a creeper gear. The direction reverser was now always electric. The A105 and A115 models could also be equipped with a 16+16 electronically controlled transmission with a 4-speed creeper gear. The GL models also now had a similar armrest as the HiTech4 models. A dual hydraulic pump was standard on the 4-cylinder models. Up to three hydraulic valves were available. A power lift was standard. Lifting capacity ranged from 3000 to 5200 kg depending on the model. Four-wheel drive and the differential lock were electrically controlled. An optional Comfort package was available, which included, among other things, front axle and cab suspension. The trailer brake valve could be obtained as either hydraulic or pneumatic.

GL models were manufactured at Agco's factory in China and HiTech4 models in Suolahti.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelValtra A75Valtra A85Valtra A95Valtra A105Valtra A115Valtra A125Valtra A135
Manufacturer nameValtraValtraValtraValtraValtraValtraValtra
Imported to FinlandYesYesYesYesYesYesYes
Years2021-2021-2021-2021-2021-2021-2021-
Engine model33 MBTN-D533 MBTN-D533 MBTN-D544 MBTN-D544 MBTN-D544 MBTN-D544 MBTN-D5
Cyl/Turbo/Intercooler3T3TI3TI4TI4TI4TI4TI
Displacement3300 cm³3300 cm³3300 cm³4400 cm³4400 cm³4400 cm³4400 cm³
Bore x stroke108×120 mm108×120 mm108×120 mm108×120 mm108×120 mm108×120 mm108×120 mm
Max power-------
Torque-------
Gears12+12/24+2412+12/24+2412+12/24+2412+12/16+1612+12/16+1612+1212+12
Synchronized gears12+12/24+2412+12/24+2412+12/24+2412+12/16+1612+12/16+1612+1212+12
Powershift gears– / hydr.– / hydr.– /hydr. / 4-step / 4-step--
Reverserelec.elec.elec.elec.elec.elec.elec.
Speeds in km/h2,0-402,0-402,0-402,0-402,0-402,0-402,0-40
Max. speed 40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h40 km/h
Hydr. flow l/min65 l/min65 l/min65 l/min98 l/min98 l/min98 l/min98 l/min
Hydraulic pressure200 bar200 bar200 bar200 bar200 bar200 bar200 bar
Lift controlselec.elec.elec.elec.elec.elec.elec.
Lift capacity3000 kg3000 kg3000 kg4300 kg4300 kg5200 kg5200 kg
PTO speeds540/1000540/1000540/1000540/1000540/1000540/1000540/1000
Brakeswet discwet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD7.447.447.448.088.0899
Front tyres 4WD320/85R24320/85R24320/85R24320/85R24320/85R24320/85R24320/85R24
Rear tyres 4WD420/85R34420/85R34420/85R34420/85R34420/85R34420/85R34420/85R34
Weight 4WD3700 kg3700 kg3700 kg4300 kg4300 kg4540 kg4540 kg
Height with cab266 cm266 cm266 cm275 cm275 cm277 cm277 cm
Length (2WD/4WD)408 cm408 cm408 cm437 cm437 cm439 cm439 cm
Wheelbase (2WD/4WD)225 cm225 cm225 cm243 cm243 cm250 cm250 cm
Fuel tank147+AB13 l147+AB13 l147+AB13 l175/180+AB13 l175/180+AB13 l175+AB13 l175+AB13 l
Cab noise level75 dB75 dB75 dB75 dB75 dB75 dB75 dB
Solid cabxxxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lock
Creeper gearopt.opt.opt.opt.opt.opt.opt.
