Valmet/Valtra 600-900

00Valtra800
00Valtra600ohjaamo
00Valtra800tehot
00Valtra800
00Valtra600ohjaamo
00Valtra800tehot
Manufacturer
Models
Valmet 600, Valmet 700, Valmet 800, Valmet 800, Valmet 900, Valmet 900
Years
1997-02
Info

The Valmet 100 series, introduced in the autumn of 1997, is one of the best examples in the tractor world of how small but continuous improvements can keep an outdated model up to date with development. The lineup was updated every few years enough to maintain the interest of buyers looking for an affordable solution. The 100 series itself was a sales success, even though competitors offered models with features like a shuttle gearbox and a quiet cabin for the same money. It is also interesting that competitors only began to bring similar basic models equipped with pedals through the floor to the Finnish market in the early 2000s.

The improvements introduced in the 865 model were expanded across the entire 100 series, including the redesigned cabin, reinforced rear axle, and lifting capacity increased to 3.3 tons with auxiliary cylinders (standard on the 800/900 models). New were the quick shift and an additional heater mounted on the roof—these were standard on the 900. The lineup was now quite clear: naturally aspirated three-cylinder 600, turbocharged three-cylinder 700, naturally aspirated four-cylinder 800, and turbocharged four-cylinder 900. The four-cylinder models had a distributor pump and a muffler placed under the engine hood. New optional equipment included a push-button clutch and an auxiliary fuel tank that increased fuel capacity to just over one hundred liters. The weight had increased by about 350 kilos compared to before.

In 2001, the engines were equipped with an electronic injection pump, and the 800 model was also fitted with a turbo. The torque of the four-cylinder engines increased, and the noise level of all models was reduced to 81 decibels.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelValmet 600Valmet 700Valmet 800Valmet 800Valmet 900Valmet 900
Manufacturer nameValmetValmetValmetValmetValmetValmet
Imported to FinlandYesYesYesYesYesYes
Years1997-021997-021997-012001-021997-012001-02
Engine model320 D/DE320 DS/DSRE420 DR420 DSRE420 DSR420 DSRE
Cyl/Turbo/Intercooler33T44T4T4T
Displacement3300 cm³3300 cm³4400 cm³4400 cm³4400 cm³4400 cm³
Bore x stroke108×120 mm108×120 mm108×120 mm108×120 mm108×120 mm108×120 mm
Rated power60/2270 hp DIN/rpm70/2270 hp DIN/rpm80/2270 hp DIN/rpm80/2270 hp DIN/rpm90/2270 hp DIN/rpm90/2270 hp DIN/rpm
Torque------
Gears8+48+48+48+416+816+8
Synchronized gears8+48+48+48+416+816+8
Powershift gearsopt.opt.opt.opt.hydr.hydr.
Speeds in km/h3,8-37,54,1-40,24,1-40,24,1-40,23,5-40,23,5-40,2
Max. speed 40.8 km/h43.7 km/h43.7 km/h43.7 km/h43.7 km/h43.7 km/h
Hydr. flow l/min37 l/min37 l/min52 l/min52 l/min52 l/min52 l/min
Hydraulic pressure180 bar180 bar190 bar190 bar190 bar190 bar
Lift controlsmech. (elec.)mech. (elec.)mech. (elec.)mech. (elec.)mech. (elec.)mech. (elec.)
Lift capacity2800 kg2800 kg3300 kg3300 kg3300 kg3300 kg
PTO speeds540/750540/750540/750540/750540/750540/750
Brakeswet discwet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 2WD777.27.27.27.2
Turning circle m 4WD9.29.29.69.69.69.6
Front tyres 2WD10.00-1610.00-1610.00-1610.00-1610.00-1610.00-16
Front tyres 4WD12.4R2413.6R2413.6R2413.6R2413.6R2413.6R24
Rear tyres 2WD16.9R3016.9R3416.9R3416.9R3416.9R3416.9R34
Rear tyres 4WD16.9R3016.9R3416.9R3416.9R3416.9R3416.9R34
Weight 2WD3160 kg3210 kg3330 kg3330 kg3360 kg3360 kg
Weight 4WD3390 kg3440 kg3560 kg3560 kg3590 kg3590 kg
Height with cab266 cm266 cm268/270 cm268/270 cm268/270 cm268/270 cm
Length (2WD/4WD)375/386 cm375/386 cm388/404 cm388/404 cm388/404 cm388/404 cm
Wheelbase (2WD/4WD)211/226 cm211/226 cm224/239 cm224/239 cm224/239 cm224/239 cm
Fuel tank73 l73 l73 l73 l73 l73 l
Cab noise level83/81 dB83/81 dB83 dB81 dB83 dB81 dB
Solid cabxxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lock
Creeper gearopt.opt.opt.opt.opt.opt.
