Siirry sivupalkkiinSiirry alaosaanValmet Mega 8400




From the Mega 8000 series, the favorite became the 8400, which was especially popular as a contract machine. After the introduction of the 8050 series, the 8400 was kept in production but received a few updates. The lifting capacity was increased to 7 tons. However, the engine represented an older generation compared to the equally powerful 8450. Autocontrol was updated to version 2.1, which included a so-called forced descent function. One of the secrets to the 8400’s popularity was the traffic tractor version, which with its 50 km/h speed, competitors still could not offer in the mid-1990s.
In the spring of 2000, the engine was replaced with a newer version. Power increased to 150 horsepower, partly thanks to new nozzles, and torque rose by as much as 105 Nm. The torque increase was 31% instead of the previous 16%. Standard equipment now included, among other things, a sturdier industrial front axle, larger tires, and longer lift arms.
In the spring of 2002, power was further increased to 160 horsepower and standard equipment included millimeter tires. The engine now featured a viscous fan. The 8400 was also available as a long wheelbase version. The 8400 was only discontinued after the introduction of the T Classic models.
This is an automated translation. Please report any issues in the translation.
| Model | Valmet 8400 | Valmet 8400 | Valmet 8400 |
|---|---|---|---|
| Manufacturer name | Valmet | Valmet | Valmet |
| Imported to Finland | Yes | Yes | Yes |
| Years | 1996-2000 | 2000-02 | 2002-04 |
| Engine model | 620DS | 620DS | 620DSIE |
| Cyl/Turbo/Intercooler | 6T | 6T | 6T |
| Displacement | 6598 cm³ | 6598 cm³ | 6598 cm³ |
| Bore x stroke | 108×120 mm | 108×120 mm | 108×120 mm |
| Rated power | 140/2200 hp DIN/rpm | 150/2200 hp DIN/rpm | 160/2200 hp DIN/rpm |
| Torque | - | - | - |
| Gears | 36+36 | 36+36 | 36+36 |
| Synchronized gears | 36+36 | 36+36 | 36+36 |
| Powershift gears | 3-step | 3-step | 3-step |
| Reverser | mech. | mech. | mech. |
| Speeds in km/h | 0,6-39,2/47,8 | 0,6-39,2/47,8 | 0,6-39,2/47,8 |
| Max. speed | 40 (50) km/h | 40 (50) km/h | 40 (50) km/h |
| Hydr. flow l/min | 73 l/min | 73 l/min | 73 l/min |
| Lift controls | elec. | elec. | elec. |
| Lift capacity | 7000 kg | 6700 kg | 6700 kg |
| PTO speeds | 540/1000/ajo | 540/1000/ajo | 540/1000/ajo |
| Brakes | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 10.2 | 10.2 | 10.2 |
| Front tyres 4WD | 14.9R28 | 16.9R28 | 480/70R28 |
| Rear tyres 4WD | 18.4R38 | 20.8R38 | 580/70R38 |
| Weight 4WD | 4870 kg | 5080 kg | 5080 kg |
| Height with cab | 280 cm | 281 cm | 284 cm |
| Length (2WD/4WD) | 475 cm | 485 cm | 485 cm |
| Wheelbase (2WD/4WD) | 256 cm | 256 cm | 256 (275) cm |
| Fuel tank | 165 l | 165 l | 165 l |
| Cab noise level | 78 dB | 77 dB | 74.5 dB |
| Solid cab | x | x | x |
| Diff. lock | disc lock | disc lock | disc lock |
| Autom. differential locks | x | x | x |
