Same Virtus J 90 – 120 / Lamborghini Nitro R 90 – 120 / Hürlimann XM.K 90 – 120
Manufacturer
Models
Same Virtus J 90, Lamborghini Nitro R 90, Same Virtus J 100, Lamborghini Nitro R 100, Same Virtus J 110, Lamborghini Nitro R 110, Same Virtus J 120, Lamborghini Nitro R 120
Years
2014-
Info
At the end of 2013, cheaper model versions Virtus J, Nitro R, and XM.K were introduced. The Model 130 was not available; instead, at the lower end, there was a less powerful version 90. The engines were the same 3.6-liter Deutz engines as in the more expensive models. The direction reverser was mechanical as standard except for model 120, where it was hydraulic. In addition to models without a quick shift and those equipped with a three-speed quick shift, a two-speed quick shift was available, giving 20+20 gears, and with crawling gears, 40+40. The 50 km/h speed was not attainable, nor was the 90-liter hydraulic pump. Two hydraulic blocks were standard. The power take-off had standard speeds of 540 and 750. The wheelbase was 7 cm shorter.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Same Virtus J 90 | Lamborghini Nitro R 90 | Same Virtus J 100 | Lamborghini Nitro R 100 | Same Virtus J 110 | Lamborghini Nitro R 110 | Same Virtus J 120 | Lamborghini Nitro R 120 |
|---|---|---|---|---|---|---|---|---|
| Options | ||||||||
| Imported to Finland | No | No | No | No | No | No | No | No |
| Years | 2014- | 2014- | 2014- | 2014- | 2014- | 2014- | 2014- | 2014- |
| First year sold | 2014 | 2014 | 2014 | 2014 | 2014 | 2014 | 2014 | 2014 |
| Engine model | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i | TCD 3.6 L04 Tier 4i |
| Cyl/Turbo/Intercooler | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI | 4TI |
| Displacement | 3620 cm³ | 3620 cm³ | 3620 cm³ | 3620 cm³ | 3620 cm³ | 3620 cm³ | 3620 cm³ | 3620 cm³ |
| Bore x stroke | 98×120 mm | 98×120 mm | 98×120 mm | 98×120 mm | 98×120 mm | 98×120 mm | 98×120 mm | 98×120 mm |
| Rated power hp/rpm ISO | 85/2200 | 85/2200 | 95/2200 | 95/2200 | 105/2200 | 105/2200 | 113/2200 | 113/2200 |
| Rated power | - | - | - | - | - | - | - | - |
| Rated speed | - | - | - | - | - | - | - | - |
| Max power hp/rpm ISO | 89/2000 | 89/2000 | 99/2000 | 99/2000 | 110/2000 | 110/2000 | 118/2000 | 118/2000 |
| Max power | - | - | - | - | - | - | - | - |
| Max speed | - | - | - | - | - | - | - | - |
| Torque Nm/rpm ISO | 358/1600 | 358/1600 | 397/1600 | 397/1600 | 440/1600 | 440/1600 | 460/1600 | 460/1600 |
| Gears | 10+10/20+20 | 10+10/20+20 | 10+10/20+20/30+30 | 10+10/20+20/30+30 | 10+10/20+20/30+30 | 10+10/20+20/30+30 | 20+20/30+30 | 20+20/30+30 |
| Synchronized gears | 10+10/20+20 | 10+10/20+20 | 10+10/20+20/30+30 | 10+10/20+20/30+30 | 10+10/20+20/30+30 | 10+10/20+20/30+30 | 20+20/30+30 | 20+20/30+30 |
| Powershift gears | -/2-step | -/2-step | -/2-step/3-step | -/2-step/3-step | -/2-step/3-step | -/2-step/3-step | 2-step/3-step | 2-step/3-step |
| Reverser | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | hydr. | hydr. |
| Max. speed | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 55 (60) l/min | 55 (60) l/min | 55 (60) l/min | 55 (60) l/min | 55 (60) l/min | 55 (60) l/min | 55 (60) l/min | 55 (60) l/min |
| Hydraulic pressure | 185 bar | 185 bar | 185 bar | 185 bar | 185 bar | 185 bar | 185 bar | 185 bar |
| Lift controls | elec. | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Lift capacity | 3565 (4855) kg | 3565 (4855) kg | 4855 kg | 4855 kg | 4855 (5410) kg | 4855 (5410) kg | 5410 kg | 5410 kg |
| PTO speeds | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 | 540/750 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 7 | 7 | 7 | 7 | 7 | 7 | 7 | 7 |
| Front tyres 4WD | 340/85R24 | 340/85R24 | 420/70R24 | 420/70R24 | 420/70R24 | 420/70R24 | 420/70R24 | 420/70R24 |
| Rear tyres 2WD | - | - | - | - | 480/70R34 | 480/70R34 | - | - |
| Rear tyres 4WD | 420/85R34 | 420/85R34 | 480/70R34 | 480/70R34 | 480/70R34 | 480/70R34 | 480/70R34 | 480/70R34 |
| Weight 4WD | 4100 kg | 4100 kg | 4200 kg | 4200 kg | 4250 kg | 4250 kg | 4250 kg | 4250 kg |
| Height with cab | 266 cm | 266 cm | 266 cm | 266 cm | 266 cm | 266 cm | 272 cm | 272 cm |
| Length (2WD/4WD) | 415 cm | 415 cm | 415 cm | 415 cm | 415 cm | 415 cm | 415 cm | 415 cm |
| Wheelbase (2WD/4WD) | 237 (2WD 233) cm | 237 (2WD 233) cm | 237 cm | 237 cm | 237 (2WD 233) cm | 237 (2WD 233) cm | 237 (2WD 233) cm | 237 (2WD 233) cm |
| Fuel tank | 145 l | 145 l | 145 l | 145 l | 145 l | 145 l | 145 l | 145 l |
| Solid cab | x | x | x | x | x | x | x | x |
| Diff. lock | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
| Creeper gear | opt. | opt. | opt. | opt. | opt. | opt. | opt. | opt. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
