Here is the English translation of the text:
Introduced in 1957, the Sametto used the same air-cooled single-cylinder direct injection diesel engine as the earlier D.A. 17. Instead of the previous four gears, it had five, and the highest gear was synchronized. In the Italian fashion, a narrower vineyard version as well as a four-wheel drive model were also available.
In 1960, as successors to the D.A. 25 and 30, the 2-cylinder Same Puledro was introduced, which was closely related to the larger 240 model. It initially had a 30-horsepower 2274 cm³ engine, but in the more common Serie B model, the displacement was increased to 2.5 liters. The Puledro had 6+2 gears or, with crawler gears, 9+3.
The successors to the Puledro were the Same Italia, equipped with an air-cooled V2 diesel, and the Atlanta, equipped with a V4. Both models had a 6+2 gearbox. Like the larger new Falcon model, these were designed with angular shapes. The frame color had changed from gray to blue. Characteristic of Same tractors, even the smaller ones featured a draft link sensing system and a dual clutch.
This is an automated translation. Please report any issues in the translation.
| Model | Same Sametto | Same Sametto 120 | Same Sametto V | Same Puledro B | Same Italia | Same Italia 35 | Same Atlanta V | Same Atlanta 45 |
|---|---|---|---|---|---|---|---|---|
| Manufacturer name | Same | Same | Same | Same | Same | Same | Same | Same |
| Imported to Finland | No | No | No | No | No | No | No | No |
| Years | 1957-60 | 1960-64 | 1964-72 | 1960-65 | 1965-68 | 1968-73 | 1965-68 | 1966-70 |
| Engine model | DA/1101 C | DA/1151 | DA 952/V | DA/1152 | DA 952/V | 025-1002 V | DA 954/V | DA 954/V |
| Cyl/Turbo/Intercooler | 1 | 1 | V2 | 2 | V2 | V2 | V4 | V4 |
| Displacement | 1140 cm³ | 1245 cm³ | 1700 cm³ | 2491 cm³ | 1700 cm³ | 1885 cm³ | 3402 cm³ | 3402 cm³ |
| Bore x stroke | 110×120 mm | 115×120 mm | 95×120 mm | 115×120 mm | 95×120 mm | 100×120 mm | 95×120 mm | 95×120 mm |
| Rated power | 18/2150 hp DIN/rpm | 22/2000 hp DIN/rpm | 26/2000 hp DIN/rpm | 35/1700 hp DIN/rpm | 30/1700 hp DIN/rpm | 32/2000 hp DIN/rpm | 40/2000 hp DIN/rpm | 42/1700 hp DIN/rpm |
| Gears | 5+1 | 6+1 | 6+2 | 6+2 | 6+2 | 6+2 | 6+2 | 6+2 |
| Synchronized gears | 1 | 1 | - | - | - | - | - | - |
| Speeds in km/h | 1,0-14,5 | 2,1-23,0 | 2,1-23,4 | 2,0-23,7 | 2,5-27,1 | 2,2-24,5 | 2,2-25,5 | 2,2-25,5 |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| PTO speeds | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo |
| Brakes | drum brakes | drum brakes | drum brakes | drum brakes | drum brakes | drum brakes | drum brakes | drum brakes |
| Steering | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Front tyres 2WD | 5.00-15 | 5.00-15 | 6.00-16 | 5.00-16 | 6.00-16 | 6.00-16 | 5.50-16 | 5.50-16 |
| Front tyres 4WD | 6.00-16 | 6.00-16 | 7.50-16 | 6.00-16 | 7.50-16 | 7.50-16 | 8.00-20 | 8.00-20 |
| Rear tyres 2WD | 9.5/9-24 | 9.5/9-24 | 9.5/9-24 | 11.2-28 | 11.2-28 | 11.2-28 | 12.4-28 | 12.4-28 |
| Rear tyres 4WD | 9.5/9-24 | 9.5/9-24 | 9.5/9-24 | 11.2-28 | 11.2-28 | 11.2-28 | 12.4-28 | 12.4-28 |
| Weight 2WD | (1060) kg | (1046) kg | (1220) kg | (1410) kg | (1280) kg | (1380) kg | (1580) kg | (1640) kg |
| Weight 4WD | (1300) kg | (1310) kg | (1340) kg | - | (1400) kg | (1500) kg | (1740) kg | (1840) kg |
| Height with cab | (134) cm | (137) cm | (134) cm | (146) cm | (142) cm | (137) cm | (149) cm | (149) cm |
| Length (2WD/4WD) | 230/240 cm | 234/232 cm | 241/243 cm | 273 cm | 266 cm | 269 cm | 281/282 cm | 289/295 cm |
| Wheelbase (2WD/4WD) | 145/150 cm | 153/142 cm | 153/142 cm | 172 cm | 174/162 cm | 171/162 cm | 183/172 cm | 191/185 cm |
| Diff. lock | no | no | no | no | no | no | no | no |
| Hydr. flow l/min | - | 9 l/min | 9 l/min | - | 12 l/min | - | 12 l/min | 12 l/min |
| Hydraulic pressure | - | 175 bar | 175 bar | - | 175 bar | 175 bar | 175 bar | 175 bar |
| Turning circle m 2WD | - | 5.8 | 5.8 | - | 6.2 | 6.2 | 6.46 | 6.46 |
| Turning circle m 4WD | - | 7.8 | 7.8 | - | 7.7 | 7.7 | 7.3 | 7.3 |
| Fuel tank | - | 60 l | 60 l | - | 45/60 l | 60 l | 35 l | 35 l |
| Creeper gear | - | - | - | opt. | - | - | - | opt. |
| Lift capacity | - | - | - | - | 900 kg | - | 1000 kg | 1000 kg |
