Siirry sivupalkkiinSiirry alaosaanSame Dorado 56-86 / Lamborghini R2.56-R2.86 / Hürlimann XA 56-86










At the end of 2004 the water-cooled-engine versions of the Same Dorado were introduced. The equivalent Lamborghini-series designation was changed to R2, while Hürlimann models retained the XA badge. Like the larger Lamborghini models, the R2 was now painted in silver metallic, and from 2006 onwards Hürlimann tractors also adopted the silver finish.
The lineup consisted of two 3-cylinder and two 4-cylinder versions, the higher-output variants in each case being turbocharged. Fuel injection was handled by individual pump units for each cylinder. On the 87-hp model the engine management was fully electronic and the electronic hand throttle featured a rev-memory button. In Finland the standard transmission was a 30+15 gearbox without a powershift but equipped with creeper gears. The Agroshift transmission, by contrast, offered 45+45 speeds thanks to a three-speed hydraulic powershift unit. An optional hydraulic reverser with push-button control was also available. The most basic version in the range had a 20+10 gearbox without creeper gears; this entry-level model was also called the Dorado Classic.
The three-point hitch lift capacity was 3,000 kg, or 3,600 kg if additional lift rams were fitted. An electric-lift linkage was offered as an extra. The cab noise level was rated at 76 dB. Parallel models included the narrower Dorado S versions for vineyards and the F versions for orchards; these narrow-track models were also offered in a more powerful 95-hp spec.
This is an automated translation. Please report any issues in the translation.
| Model | Same Dorado 56 | Lamborghini R2.56 | Same Dorado 66 | Lamborghini R2.66 | Same Dorado 76 | Lamborghini R2.76 | Same Dorado 86 | Lamborghini R2.86 |
|---|---|---|---|---|---|---|---|---|
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 2005-09 | 2005-09 | 2005-09 | 2005-09 | 2005-09 | 2005-09 | 2005-09 | 2005-09 |
| Engine model | 1000.3 W | 1000.3 W | 1000.3 WT | 1000.3 WT | 1000.4 W | 1000.4 W | 1000.4 WT | 1000.4 WT |
| Cyl/Turbo/Intercooler | 3 | 3 | 3T | 3T | 4 | 4 | 4T | 4T |
| Displacement | 3000 cm³ | 3000 cm³ | 3000 cm³ | 3000 cm³ | 4000 cm³ | 4000 cm³ | 4000 cm³ | 4000 cm³ |
| Bore x stroke | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm | 105×115,5 mm |
| Rated power | - | - | - | - | - | - | - | - |
| Torque | - | - | - | - | - | - | - | - |
| Gears | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 |
| Synchronized gears | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 | 30+15/45+45 |
| Powershift gears | -/3-step | -/3-step | -/3-step | -/3-step | -/3-step | -/3-step | -/3-step | -/3-step |
| Reverser | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) | mech. (hydr.) |
| Speeds in km/h | 0,2-40 | 0,2-40 | 0,2-40 | 0,2-40 | 0,2-40 | 0,2-40 | 0,2-40 | 0,2-40 |
| Hydr. flow l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min | 54 l/min |
| Hydraulic pressure | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar | 180 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 3000 (3600) kg | 3000 (3600) kg | 3000 (3600) kg | 3000 (3600) kg | 3000 (3600) kg | 3000 (3600) kg | 3000 (3600) kg | 3000 (3600) kg |
| PTO speeds | 540/750 | 540/750 | 540/750 | 540/750 | 540/750/1000 | 540/750/1000 | 540/750/1000 | 540/750/1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 7.3 | 7.3 | 7.3 | 7.3 | 7.6 | 7.6 | 7.6 | 7.6 |
| Front tyres 4WD | 11.2R24 | 11.2R24 | 11.2R24 | 11.2R24 | 320/70R24 | 320/70R24 | 320/70R24 | 320/70R24 |
| Rear tyres 4WD | 12.4R36 | 12.4R36 | 12.4R36 | 12.4R36 | 480/70R30 | 480/70R30 | 480/70R30 | 480/70R30 |
| Weight 4WD | 2750 kg | 2750 kg | 2800 kg | 2800 kg | 2900 kg | 2900 kg | 2950 kg | 2950 kg |
| Height with cab | 240 cm | 240 cm | 240 cm | 240 cm | 244 cm | 244 cm | 244 cm | 244 cm |
| Length (2WD/4WD) | 361 cm | 361 cm | 361 cm | 361 cm | 374 cm | 374 cm | 374 cm | 374 cm |
| Wheelbase (2WD/4WD) | 206 cm | 206 cm | 212/206 cm | 212/206 cm | 224/219 cm | 224/219 cm | 224/219 cm | 224/219 cm |
| Fuel tank | 90 l | 90 l | 90 l | 90 l | 90 l | 90 l | 90 l | 90 l |
| Cab noise level | 76 dB | 76 dB | 76 dB | 76 dB | 76 dB | 76 dB | 76 dB | 76 dB |
| Solid cab | x | x | x | x | x | x | x | x |
| Diff. lock | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs | differential lock with cogs |
| Creeper gear | x | x | x | x | x | x | x | x |
| Turning circle m 2WD | - | - | 6.12 | 6.12 | 6.4 | 6.4 | 6.4 | 6.4 |
| Front tyres 2WD | - | - | 7.50-16 | 7.50-16 | 7.50-18 | 7.50-18 | 7.50-18 | 7.50-18 |
| Rear tyres 2WD | - | - | 12.4R36 | 12.4R36 | 480/70R30 | 480/70R30 | 480/70R30 | 480/70R30 |
| Weight 2WD | - | - | 2600 kg | 2600 kg | 2700 kg | 2700 kg | 2750 kg | 2750 kg |
