Same Diamond II / Lamborghini Victory Plus

02LamborghiniVictory1
02LamborghiniVictoryOhjaamo
02SameDiamond
02SameDiamondOhjaamo
02LamborghiniVictory1
02LamborghiniVictoryOhjaamo
02SameDiamond
02SameDiamondOhjaamo
Manufacturer
Models
Same Diamond II 230, Lamborghini Victory Plus 230, Same Diamond II 260, Lamborghini Victory Plus 260
Years
2001-2004
Info

Here is the translation to English:

At the beginning of 2001, the Same Group’s flagship models underwent minor improvements. At the top of the range, torque figures were now recorded at 1040 Nm at 1350–1750 rpm, and minimum fuel consumption had dropped below 200 grams/kWh. In the cab, some of the controls had been updated, but the noise level remained at 76 dB. The more efficient air conditioning unit’s coils were located under the seat. There were now a total of 15 work lights. The gear speeds were now slightly faster, and at least in theory, the top speed exceeded 50 km/h by a couple of kilometers.

Familiar features from before included the 40+40 transmission with a 4-stage powershift, a closed hydraulic system, 10,500 kg lifting capacity, and suspended front axle and cab.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelSame Diamond II 230Lamborghini Victory Plus 230Same Diamond II 260Lamborghini Victory Plus 260
Options
Imported to FinlandYesYesYesYes
Years2001-20042001-20042001-20042001-2004
First year sold2001200120012001
Last year sold2004200420042004
Engine modelBF6L1013FCBF6L1013FCBF6L1013FCBF6L1013FC
Cyl/Turbo/Intercooler6TI6TI6TI6TI
Displacement7146 cm³7146 cm³7146 cm³7146 cm³
Bore x stroke108×130 mm108×130 mm108×130 mm108×130 mm
Rated power hp/rpm DIN230/2350230/2350260/2350260/2350
Rated power230230260260
Rated speed2350235023502350
Torque Nm/rpm DIN890/1350890/13501040/13501040/1350
Gears40+4040+4040+4040+40
Synchronized gears40+4040+4040+4040+40
Powershift gears4-step4-step4-step4-step
Reverserhydr.hydr.hydr.hydr.
Speeds in km/h0,48-50,00,48-50,00,48-50,00,48-50,0
Max. speed 40/50 km/h40/50 km/h40/50 km/h40/50 km/h
Hydr. flow l/min120 l/min120 l/min120 l/min120 l/min
Lift controlselec.elec.elec.elec.
Lift capacity10500 kg10500 kg10500 kg10500 kg
PTO speeds1000100010001000
Brakeswet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.
Turning circle m 4WD12.212.212.212.2
Front tyres 4WD520/70R34520/70R34600/70R30600/70R30
Rear tyres 4WD620/85R42620/85R42710/70R38710/70R38
Weight 4WD8350 kg8350 kg8350 kg8350 kg
Height with cab323 cm323 cm323 cm323 cm
Length (2WD/4WD)513 cm513 cm513 cm513 cm
Wheelbase (2WD/4WD)309 cm309 cm309 cm309 cm
Fuel tank550 l550 l550 l550 l
Cab noise level76 dB76 dB76 dB76 dB
Solid cabxxxx
Diff. lockdisc lockdisc lockdisc lockdisc lock
Autom. differential locksxxxx
Air suspension seatxxxx
Air conditioningxxxx
Trip computerxxxx
Creeper gearxxxx
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
