Same D.A. 12 – D.A. 30

Manufacturer
Models
Same D.A. 12, Same D.A. 17, Same D.A. 25, Same D.A. 30
Years
1952-61
Info

In 1952, the Samen D.A. models were introduced; these were the brand's first diesel-powered tractors after the war. The designation D.A. came from the engine's air cooling. The 1-cylinder D.A. 12 had a power of 12.5 hp, and the 2-cylinder D.A. 25 had 25 hp. A year later, an even more powerful 1-cylinder D.A. 17 was introduced. The D.A. 25 DT was the world's first mass-produced four-wheel-drive tractor. The transmission in all these tractors was a 4+1 gear system. The 1-cylinder models were just over 2 meters long. At this stage, Same was a very small and financially weak company, but the new tractors proved competitive, and by 1955, 1,750 tractors had already been manufactured.

In 1957, the successor to the D.A. 25 was introduced as the D.A. 30. Its maximum power was 34 hp, it had 6+1 gears, and a differential lock was standard. At the end of the 1950s, Same's color scheme changed: previously, the rims and grill were green. Going forward, the rims remained green, while the grill, chassis, and engine were dark gray.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelSame D.A. 12Same D.A. 17Same D.A. 25Same D.A. 30
Options
Manufacturer nameSameSameSameSame
Imported to FinlandNoNoNoNo
Years1952-571953-571952-581957-61
First year sold1952195319521957
Last year sold1957195719581961
Engine modelD.A. 1101D.A. 1101D.A. 1102D.A. 1102/C
Cyl/Turbo/Intercooler1122
Displacement1140 cm³1140 cm³2280 cm³2280 cm³
Bore x stroke110×120 mm110×120 mm110×120 mm110×120 mm
Rated power hp/rpm DIN12,5/170017/200025/170034/2000
Rated power12.5172534
Rated speed1700200017002000
Gears4+14+14+16+1
Speeds in km/h3,2-17,22,7-14,44,4-24,31,0-24,0
Lift controlsmech.mech.mech.mech.
PTO speeds738---
Brakesdrum brakesdrum brakesdrum brakesdrum brakes
Steeringmech.mech.mech.mech.
Turning circle m 2WD-4.46.8-
Turning circle m 4WD--8.4-
Front tyres 2WD5.00-155.00-154.00-195.50-16
Front tyres 4WD--7.50-207.50-20
Rear tyres 2WD7.50-168.3/8-2411.2/10-2811.2/10-28
Rear tyres 4WD--11.2/10-2811.2/10-28
Weight 2WD(1000) kg(1050) kg(1500) kg(1650) kg
Weight 4WD--(1690) kg(1805) kg
Height with cab(119) cm(132) cm(142) cm(149) cm
Length (2WD/4WD)207 cm215 cm270/266 cm267/266 cm
Wheelbase (2WD/4WD)126 cm126 cm172/173 cm172/173 cm
Fuel tank--30 l-
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
