Siirry sivupalkkiinSiirry alaosaanRenault Arès 715 RZ – 825 RZ




In the spring of 1998, the Arès 725 and 735 were introduced. The smaller model gradually replaced the 720, while the more powerful one expanded the lineup upwards. Both models featured an intercooler-equipped Deere 6.8-liter engine. The air filter was cleaned using the flow generated by the exhaust gases. The front axle lock was automatic. The rear axle was stronger than before. The hydraulics were open as standard, but the pump output was increased to 110 liters per minute.
At the end of 1998, the Arès 815 and 825 were introduced. The difference between these models and the 700 series was the Funk full powershift. The direction changer was electro-hydraulic. Load-sensing hydraulics were standard.
The Arès 710 only received a successor in 2000, when the new 715 was introduced. The engine was still from an older series compared to the equally powerful 815, and the hydraulics output was only 60 l/min.
This is an automated translation. Please report any issues in the translation.
| Model | Renault Arès 715 | Renault Arès 725 | Renault Arès 735 | Renault Arès 815 | Renault Arès 825 |
|---|---|---|---|---|---|
| Manufacturer name | Renault | Renault | Renault | Renault | Renault |
| Imported to Finland | No | No | No | No | No |
| Years | 2000-2002 | 1998-2002 | 1998-2002 | 1998-2002 | 1998-2002 |
| Engine model | DPS 6068 TRT50 | DPS 6068 HRT51 | DPS 6068 HRT52 | DPS 6068 TRT52 | DPS 6068 HRT51 |
| Cyl/Turbo/Intercooler | 6T | 6TI | 6TI | 6T | 6TI |
| Displacement | 6788 cm³ | 6788 cm³ | 6788 cm³ | 6788 cm³ | 6788 cm³ |
| Bore x stroke | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm | 106,5×127 mm |
| Rated power | 145/2200 hp DIN/rpm | 175/2200 hp DIN/rpm | 194/2200 hp DIN/rpm | 150/2200 hp DIN/rpm | 175/2200 hp DIN/rpm |
| Torque | - | - | - | - | - |
| Gears | 32+32 | 32+32 | 32+32 | 18+8 | 18+8 |
| Synchronized gears | 32+32 | 32+32 | 32+32 | powershift | powershift |
| Powershift gears | 4-step | 4-step | 4-step | powershift | powershift |
| Reverser | hydr. | hydr. | hydr. | hydr. | hydr. |
| Speeds in km/h | 2,1-38,5 | 2,1-38,5 | 2,1-38,5 | 2,3-38,0 | 2,3-38,0 |
| Max. speed | 40 km/h | 40 km/h | 40 km/h | 40 km/h | 40 km/h |
| Hydr. flow l/min | 60 l/min | 110 l/min | 110 l/min | 110 l/min | 110 l/min |
| Lift controls | elec. | elec. | elec. | elec. | elec. |
| Lift capacity | 10740 kg | 11330 kg | 11330 kg | 11330 kg | 11330 kg |
| PTO speeds | 540/1000 | 750/1000 | 750/1000 | 750/1000 | 750/1000 |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 4WD | 9.8 | 9.8 | 9.8 | 9.8 | 9.8 |
| Front tyres 4WD | 16.9R28 | 16.9R28 | 16.9R30 | 16.9R28 | 16.9R28 |
| Rear tyres 4WD | 20.8R38 | 20.8R38 | 20.8R42 | 20.8R38 | 20.8R38 |
| Weight 4WD | 7140 kg | 8160 kg | 8420 kg | 7920 kg | 8220 kg |
| Height with cab | 302 cm | 302 cm | 308 cm | 303 cm | 303 cm |
| Length (2WD/4WD) | 497 cm | 497 cm | 497 cm | 497 cm | 497 cm |
| Wheelbase (2WD/4WD) | 288 cm | 288 cm | 288 cm | 288 cm | 288 cm |
| Fuel tank | 300 l | 300 l | 300 l | 300 l | 300 l |
| Solid cab | x | x | x | x | x |
| Diff. lock | disc lock | disc lock | disc lock | disc lock | disc lock |
| Autom. differential locks | x | x | x | x | x |
| Air conditioning | x | x | x | x | x |
| Creeper gear | opt. | opt. | opt. | opt. | opt. |
