Renault 385, Master 1 – Master 2

67RenaultMaster
Manufacturer
Models
Renault 385 MWM, Renault 385 Ren., Renault Master 1, Renault Master 2
Years
1963-69
Info

In the spring of 1963, the 55-horsepower 385 was introduced as the successor to the earlier 60-horsepower Renault 108, which had been manufactured by the Italian company Motomeccanica. A year later, the model designation was changed to Master, borrowed from Porsche. There were two engine options available. The more popular Master 2 used Renault’s 3.0-liter water-cooled direct injection diesel engine. The alternative was an air-cooled engine from MWM. In the 385, it was a 2.7-liter, and in the Master 1, it was increased to 3.0 liters. At the very beginning, it was a 55-horsepower pre-chamber diesel, but it was quickly replaced by a 60-horsepower direct injection diesel.

The gearbox was a partially synchronized 10+2-speed with crawler gears as standard. Besides the engine, there were many other options in the technology as well. The clutch was either an 11″ single-plate or an 11″ dual-clutch. Steering was either manual or power-assisted. The brakes were dry hydraulic disc brakes. In 1966, four-wheel-drive models became available, equipped with a Selene front axle.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelRenault 385 MWMRenault 385 Ren.Renault Master 1Renault Master 2
Options
Manufacturer nameRenaultRenaultRenaultRenault
Imported to FinlandNoNoNoNo
Years1963-641963-641964-671964-69
First year sold1963196319641964
Last year sold1964196419671969
Engine modelMWM AKD 110,5591 AlfaMWM D 308-4591 Alfa
Cyl/Turbo/Intercooler4444
Displacement2672 cm³3017 cm³2977 cm³3017 cm³
Bore x stroke90×105 mm98×100 mm95×105 mm98×100 mm
Rated power hp/rpm DIN55/250055/250060/250055/2500
Rated power55556055
Rated speed2500250025002500
Torque Nm/rpm DIN--191/1590-
Gears10+210+210+210+2
Synchronized gears4444
Speeds in km/h0,9-23,40,9-23,40,9-23,40,9-23,4
Max. speed --25.6 km/h-
Hydr. flow l/min27 l/min27 l/min27 l/min27 l/min
Lift controlsmech.mech.mech.mech.
Lift capacity1600 kg1600 kg1600 kg1600 kg
PTO speeds540/ajo540/ajo540/ajo540/ajo
Brakesdry discdry discdry discdry disc
Steeringmech.mech.mech./powermech./power
Turning circle m 2WD7,1 jarrulla7,1 jarrulla7,1 jarrulla7,1 jarrulla
Front tyres 2WD6.50-206.50-206.50-206.50-20
Rear tyres 2WD14.9-2814.9-2816.9-3016.9-30
Weight 2WD(2763) kg(2746) kg(2745) kg(2670) kg
Weight 4WD--(3120) kg-
Height with cab(190) cm(190) cm237/244 cm237/244 cm
Length (2WD/4WD)384 cm384 cm383/396 cm383/396 cm
Wheelbase (2WD/4WD)222 cm222 cm223/234 cm223/234 cm
Fuel tank80 l80 l80 l80 l
Creeper gearxxxx
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
