Oliver 66-88

Manufacturer
Models
Oliver 66, Oliver 66 Diesel, Oliver 77, Oliver 77 Diesel, Oliver 88, Oliver 88 Diesel
Years
1947-54
Info

Oliver was one of the first manufacturers to develop a model series that used as many interchangeable components as possible. In 1947, the model 88 was introduced above the 60 and 70 models, featuring a similar design to them. However, this was a short-lived intermediate phase.

In 1948, the Fleetline was introduced, which included the 4-cylinder 66 as well as the 6-cylinder 77 and 88. The appearance that distinguished it from competitors was primarily the fully sheet metal-covered engine compartment. The engines were produced in Waukesha. The lineup included HC models for gasoline, KD models for petrol, as well as later introduced diesel and propane versions. The diesels initially had technical problems but quickly replaced the petrol versions. All three models were available in Row Crop, Standard, Industrial, and Orchard versions. The Row Crop models could be equipped either with two front wheels placed in the center or with a wide, adjustable front axle, and their rear wheels were larger than those of the Standard models. Operator comfort was one of the most important design criteria for the new series. The noise level at the operator's seat was below 85 decibels, and the new Ridemaster seat suspension was complex. The power take-off was equipped with a separate clutch, making it one of the first tractors to have this feature. In 1950, the Hydra-Lectric was introduced as an optional feature — a hydraulic two-point hitch with electromagnetic working depth control. The first Fleetline tractors had band brakes that affected the drivetrain and included steering brakes. Disc brakes were introduced in 1951.

In 1952, the series was expanded with the similarly styled 99, which was, however, largely the same tractor as the earlier, unstyled 99.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelOliver 66Oliver 66 DieselOliver 77Oliver 77 DieselOliver 88Oliver 88 Diesel
Options
Manufacturer nameOliverOliverOliverOliverOliverOliver
Imported to FinlandYesYesYesYesYesYes
Years1949-541951-541948-541951-541947-541949-54
First year sold194919511948195119471949
Last year sold195419541954195419541954
Cyl/Turbo/Intercooler446666
Displacement2118 cm³2118 cm³3177 cm³3177 cm³3784 cm³3784 cm³
Bore x stroke84,1×95,3 mm84,1×95,3 mm84,1×95,3 mm84,1×95,3 mm88,9×101,6 mm88,9×101,6 mm
Power252533364444
Power speed160016001600160016001600
Rated power hp/rpm SAE25/160025/160033/160036/160044/160044/1600
Gears6+26+26+26+26+26+2
Speeds in km/h4,0-18,74,0-18,34,0-18,74,0-18,74,0-18,94,0-18,9
Lift controlsmech.mech.mech.mech.mech.mech.
PTO speeds(533)(533)(533)(533)(533)(533)
Brakesband/disc brakesband/disc brakesband/disc brakesband/disc brakesband/disc brakesband/disc brakes
Steeringmech.mech.mech.mech.mech.mech.
Front tyres 2WD5.00-155.00-155.50-165.50-166.00-166.00-16
Rear tyres 2WD10-24/9-3810-24/10-3812-26/11-3813-26/12-3813-26/13-3813-26/13-38
Weight 2WD(1207) kg(1721) kg(1831) kg(2185) kg(2245) kg(2576) kg
Height with cab(135) cm(135) cm(156) cm(156) cm(163) cm(163) cm
Length (2WD/4WD)316/329 cm316/329 cm329/353 cm329/353 cm339/360 cm339/360 cm
Wheelbase (2WD/4WD)187/220 cm187/220 cm198/231 cm198/231 cm201/238 cm201/238 cm
Fuel tank38 l38 l62 l62 l76 l76 l
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
