Hela D 415 – D 420, D 218

Manufacturer
Models
Hela D 415, Hela D 218, Hela D 218 L, Hela D 420, Hela D 420, Hela D 416
Years
1959-73
Info

Since 1959, Hela tractors received a new hood design. The grille was now tilted forward diagonally and was the same color as the tractor. A larger portion of the tractors were painted red, previously used mainly for export markets, instead of green. Some earlier models also got the new hood, such as the D 115 and D 315.

In the 15-horsepower class, the new model was the D 415, which was lighter and had a shorter wheelbase than the two previously mentioned models. The engine was a 1.1-liter single-cylinder Hela. It was available with both water and air cooling. Hela did not produce any other air-cooled models. The 6-speed transmission was also in-house production, and a new feature was two reverse gears. The power take-off was standard equipment, while the lifting device was an optional extra as with other Hela models.

The successor to the D 117 was the D 218, which was still available with both air- and water-cooled MWM engines. New features included a 6+2 transmission, a power take-off with two speeds and drive power, and a weight transfer system.

In 1964, the D 218 was replaced by the D 420, which remained in production until 1973. The MWM engine was higher-revving than before. The appearance was updated in 1966 with a split front grille.

From 1967 onward, Hela began shifting from its own engines back to MWM. The smallest model in the range, the D 416, had an air-cooled 2-cylinder 1.0-liter 16-horsepower engine. The transmission was Hela’s 6+2. Red had now become a more popular color than green. The front axle with suspension remained standard, unlike many competitors.

Technical data
ModelHela D 415Hela D 218Hela D 218 LHela D 420Hela D 420Hela D 416
Options
Imported to FinlandNoNoNoNoNoNo
Years1956-601961-631961-6319631964-731967-71
First year sold195619611961196319641967
Last year sold196019631963196319731971
Engine modelAE 1MWM KD 211 ZMWM AKD 311 ZMWM KD 110.5 ZMWM KD 1105 Z / D 208-2MWM D 301-2
Cyl/Turbo/Intercooler122222
Displacement1082 cm³1248 cm³1400 cm³1336 cm³1448 cm³1005 cm³
Bore x stroke105x125 mm85x110 mm90x110 mm90x105 mm95x105 mm80x100 mm
Rated power hp/rpm DIN15,5/198018/198018/198020/250020/220016/2200
Rated power15.51818202016
Rated speed198019801980250022002200
Torque Nm/rpm DIN57/?-----
Gears6+16+26+26+26+26+2
Speeds in km/h1,9-20,01,4-19,51,4-19,51,3-19,51,3-19,51,3-19,4
Lift controls(mek.)(mek.)(mek.)(mek.)(mek.)mek.
PTO speeds540559/980/ajo559/980/ajo577/ajo577/ajo577
Brakespaisuntaj.paisuntaj.paisuntaj.paisuntaj.paisuntaj.paisuntaj.
Steeringmek.mek.mek.mek.mek.mek.
Turning circle m 2WD3,8 with brake6,26,26,46,43,8 with brake
Front tyres 2WD5.00-165.00-165.00-165.00-165.00-164.50-16
Rear tyres 2WD8-249-249-249-249-249-24
Weight 2WD(1260) kg(1390) kg(1390) kg(1390) kg(1390) kg(1250) kg
Height with cab(130) cm(120) cm(120) cm(120) cm(120) cm(122) cm
Length (2WD/4WD)260 cm290 cm290 cm290 cm290 cm295 cm
Wheelbase (2WD/4WD)178 (182) cm180 cm180 cm180 cm180 cm178 cm
Fuel tank28 l28 l28 l35 l35 l35 l
Creeper gearoption-----
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information. There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed. Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
