Agrifull A 35 – A 80 S
Manufacturer
Models
Agrifull A 35, Agrifull A 50, Agrifull A 50 S, Agrifull A 55, Agrifull A 65, Agrifull A 70, Agrifull A 70 S, Agrifull A 80, Agrifull A 80 S
Years
1991-95
Info
In 1991, Agrifull models received the letter A as their model designation. The changes compared to the previous models were technically minor. The A 35 was still a small tractor different from the others, equipped with a Lombardini engine. The A 50 also differed from the other models. Among other things, it had a 12+4 gearbox, only a 45-degree turning angle in the four-wheel-drive model, and greater lifting capacity than the A 55 and A 65, which came standard with an 8+2 gearbox. Starting from the A55 model, the lifting device featured Lift-O-Matic, a quick operation borrowed from Fiat. The A 70 and A 80 had a direction reverser and a lifting capacity of 3.5 tons.
In 1993, the three models were redesigned into the S model.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Agrifull A 35 | Agrifull A 50 | Agrifull A 50 S | Agrifull A 55 | Agrifull A 65 | Agrifull A 70 | Agrifull A 70 S | Agrifull A 80 | Agrifull A 80 S |
|---|---|---|---|---|---|---|---|---|---|
| Manufacturer name | Agrifull | Agrifull | Agrifull | Agrifull | Agrifull | Agrifull | Agrifull | Agrifull | Agrifull |
| Imported to Finland | No | No | No | No | No | No | No | No | No |
| Years | 1991-95 | 1991-93 | 1993-95 | 1991-95 | 1991-95 | 1991-94 | 1993-95 | 1991-93 | 1993-95 |
| First year sold | 1991 | 1991 | 1993 | 1991 | 1991 | 1991 | 1993 | 1991 | 1993 |
| Last year sold | 1995 | 1993 | 1995 | 1995 | 1995 | 1994 | 1995 | 1993 | 1995 |
| Engine model | LWD1503 | 8035.06 | 8035.06 | 8035.06 | 8045.06 | 8045.06 | 8045.06 | 8045.06 | 8045.06 |
| Cyl/Turbo/Intercooler | 3 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Displacement | 1551 cm³ | 2710 cm³ | 2710 cm³ | 2710 cm³ | 3613 cm³ | 3613 cm³ | 3613 cm³ | 3613 cm³ | 3613 cm³ |
| Bore x stroke | 88×85 mm | 100×115 mm | 100×115 mm | 100×115 mm | 100×115 mm | 100×115 mm | 100×115 mm | 100×115 mm | 100×115 mm |
| Rated power hp/rpm DIN | 35/2800 | 50/2500 | 50/2500 | 55/2500 | 65/2500 | 70/2500 | 70/2500 | 80/2500 | 80/2500 |
| Rated power | 35 | 50 | 50 | 55 | 65 | 70 | 70 | 80 | 80 |
| Rated speed | 2800 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 |
| Torque Nm/rpm DIN | 102/2500 | ?/1300 | ?/1300 | ?/1400 | ?/1400 | ?/1500 | ?/1500 | ?/1400 | ?/1400 |
| Gears | 16+16 | 12+4 | 12+4 | 8+2/12+3 | 8+2/12+3 | 12+12 (8+2) | 12+12 | 12+12 | 12+12 |
| Synchronized gears | 16+16 | 12+4 | 12+4 | 8+2/12+3 | 8+2/12+3 | 12+12 (8+2) | 12+12 | 12+12 | 12+12 |
| Reverser | mech. | opt. | opt. | - | - | mech. | mech. | mech. | mech. |
| Speeds in km/h | 0,7-29,8 | 1,3-27,5 | 1,3-27,5 | 2,9-26,5 | 2,9-28,5 | 1,8-29,2/ 2,2-35,7 | 1,8-29,2/ 2,2-35,7 | 1,8-29,2/ 2,2-35,7 | 1,8-29,2/ 2,2-35,7 |
| Max. speed | - | 31.6 km/h | 31.6 km/h | 29 km/h | 30.3 km/h | 32,8/40,7 km/h | 32,8/40,7 km/h | 32,8/40,7 km/h | 32,8/40,7 km/h |
| Hydr. flow l/min | 22.8 l/min | 34.5 l/min | 34.5 l/min | - | - | 34.5 l/min | 34.5 l/min | 34.5 l/min | 34.5 l/min |
| Hydraulic pressure | 180 bar | 190 bar | 190 bar | 190 bar | 190 bar | 190 bar | 190 bar | 190 bar | 190 bar |
| Lift controls | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Lift capacity | 1160/1375 kg | 2125 kg | 2125 kg | 1745 kg | 1745 kg | 3565 (1745) kg | 3565 kg | 3565 kg | 3565 kg |
| PTO speeds | 540 | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo | 540/ajo |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 2WD | 6.02 | - | - | - | - | - | - | - | - |
| Turning circle m 4WD | 6.42 | - | - | - | - | - | - | - | - |
| Front tyres 2WD | 5.00-15 | 6.00-16 | 6.00-16 | 6.00-16 | 7.50-16 | 7.50-16 | 7.50-16 | 7.50-20 | 7.50-20 |
| Front tyres 4WD | 9.0/75-16 | 9.50-20 | 9.50-20 | 9.50-20 | 12.4R20 | 11.2-24 | 12.4-24 | 13.6-24 | 12.4-24 |
| Rear tyres 2WD | 11.2-20 | 13.6-28 | 13.6-28 | 13.6-28 | 14.9-30 | 16.9-30 | 13.6-36 | 16.9-34 | 13.6-38 |
| Rear tyres 4WD | 11.2-24 | 13.6-28 | 13.6-28 | 13.6-28 | 14.9-30 | 16.9-30 | 13.6-36 | 16.9-34 | 13.6-38 |
| Weight 2WD | 1300 kg | 2125 kg | 2125 kg | 2180 kg | 2335 kg | 2490 kg | 2490 kg | 2630 kg | 2630 kg |
| Weight 4WD | 1400 kg | 2375 kg | 2375 kg | 2360 kg | 2540 kg | 2790 kg | 2790 kg | 2960 kg | 2960 kg |
| Height with cab | 218 cm | 237 cm | 232 cm | 237 cm | 251 cm | 250 cm | 250 cm | 250 cm | 250 cm |
| Length (2WD/4WD) | 297 cm | 298/297 cm | 298/297 cm | 320/328 cm | 332/343 cm | 347/356 cm | 347/346 cm | 351/348 cm | 351/348 cm |
| Wheelbase (2WD/4WD) | 170 cm | 200/190 cm | 200/190 cm | 205/201 cm | 217/213 cm | 231/225 cm | 231/225 cm | 231/225 cm | 231/225 cm |
| Solid cab | - | - | - | opt. | opt. | opt. | opt. | opt. | opt. |
| Diff. lock | differential lock with cogs | opt. | opt. | opt. | opt. | opt. | opt. | opt. | opt. |
| Creeper gear | x | opt. | opt. | opt. | opt. | opt. | opt. | opt. | opt. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
