Agrifull 35-80

Manufacturer
Models
Agrifull 30, Agrifull 40, Agrifull 35, Agrifull 50, Agrifull 55 LM, Agrifull 55, Agrifull 63 Turbo, Agrifull 65, Agrifull 70, Agrifull 80
Years
1985-91
Info

Since 1985, Agrifull tractors primarily used Fiat technology. The smallest models in the lineup were the 30 and 40, which featured Fiat's 28- and 42-horsepower diesels. The 2-cylinder Piccola diesel, however, had not been used in Fiat models for a few years. The closest equivalent to these models in Fiat’s lineup was the mid-1970s 420.

Models 50 through 80 shared the same technology as the Fiatagri 66 series. There was no Fiat equivalent for the model 63 Turbo. The equipment on Agrifull tractors was more basic. The particularly stripped-down model introduced in 1986 was the 65, which was essentially a Fiat 640 equipped with hydrostatic steering. The 8+2 transmission in Agrifulls came from Universal. In contrast, the Fiat 66 series featured a 12+4 transmission. A novelty in Agrifull models was the option for a 750 rpm power take-off (PTO). These models were sold, among other places, in Norway.

In 1989, the Agrifull 35, a small tractor corresponding to the Fiatagri 35-66, was introduced, featuring a Lombardini 1.6-liter diesel engine and a 16+16 transmission equipped with creep gears.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelAgrifull 30Agrifull 40Agrifull 35Agrifull 50Agrifull 55 LMAgrifull 55Agrifull 63 TurboAgrifull 65Agrifull 70Agrifull 80
Manufacturer nameAgrifullAgrifullAgrifullAgrifullAgrifullAgrifullAgrifullAgrifullAgrifullAgrifull
Imported to FinlandNoNoNoNoNoNoNoNoNoNo
Years1986-901986-901989-911989-911985-911987-911988-911986-911986-911986-91
Engine model80258035.01LWD15038035.068035.068035.068035.068045.068045.068045.06
Cyl/Turbo/Intercooler2333333T444
Displacement1560 cm³2339 cm³1551 cm³2710 cm³2710 cm³2710 cm³2710 cm³3613 cm³3613 cm³3613 cm³
Bore x stroke95×110 mm95×110 mm88×85 mm100×115 mm100×115 mm100×115 mm100×115 mm100×115 mm100×115 mm100×115 mm
Rated power28/2400 hp DIN/rpm42/2200 hp DIN/rpm35/2800 hp DIN/rpm50/2500 hp DIN/rpm55/2500 hp DIN/rpm55/2500 hp DIN/rpm63/2500 hp DIN/rpm65/2500 hp DIN/rpm70/2500 hp DIN/rpm80/2500 hp DIN/rpm
Gears6+2/8+86+216+168+2/12+48+28+2/12+412+48+212+412+4
Reverser-/mech.-mech.opt.opt.opt.opt.opt.opt.opt.
Speeds in km/h2,7-26,22,7-25,80,7-30,01,3-27,52,6-26,52,6-26,51,8-30,02,6-26,21,7-28,31,7-35,5
Lift controlsmech.mech.mech.mech.mech.mech.mech.mech.mech.mech.
PTO speeds540540540540/ajo540/ajo540/ajo540/ajo540/ajo540/ajo540/ajo
Brakesband brakesband brakeswet discwet discwet discwet discwet discband brakeswet discwet disc
Steeringmech.mech.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Front tyres 2WD5.00-155.00-155.00-156.00-166.00-166.00-167.50-167.50-167.50-167.50-18
Rear tyres 2WD11.2-2412.4-2811.2-2412.4-2812.4-3212.4-3214.9-3014.9-3013.6-3613.6-36
Weight 2WD1100 kg1650 kg1300 kg1810 kg2010 kg2120 kg2200 kg2250 kg2580 kg2630 kg
Length (2WD/4WD)271 cm288 cm297 cm323/324 cm320/328 cm342/346 cm364 cm343 cm348/356 cm350/359 cm
Wheelbase (2WD/4WD)170 cm190/186 cm170 cm200/190 cm205/201 cm218-221/212-219 cm218-221/212-219 cm216 cm231/225 cm231/225 cm
Hydr. flow l/min-16 l/min22.8 l/min26,8/34,5 l/min26,8/29,4 l/min26,8/34,5 l/min26,8/34,5 l/min26.4 l/min34.5 l/min34.5 l/min
Hydraulic pressure-150 bar180 bar190 bar195 bar195 bar195 bar194 bar190 bar190 bar
Front tyres 4WD-8.00-209.0/75-168.00-208.3-248.00-2411.2-2011.2-2412.4R2012.4-24
Rear tyres 4WD-12.4-2811.2-2412.4-2812.4-3212.4-3214.9-2812.4-3613.6-3613.6-36
Weight 4WD-1800 kg1400 kg2030 kg2220 kg2300 kg2350 kg2370 kg2880 kg2960 kg
Torque----------
Synchronized gears--16+168+2/12+48+28+2/12+412+48+212+412+4
Lift capacity--1160 kg1914 kg1914 kg1914 kg1914 kg1940 kg2900 (3565) kg2900 (3565) kg
Turning circle m 2WD--6.02-------
Turning circle m 4WD--6.42-------
Height with cab--199 cm237 cm236 cm236 cm237 cm251 cm254 cm254 cm
Fuel tank--32 l45 l61 l73 l73 l61 (73) l73 (98) l73 (98) l
Cab noise level--84 dB-84 dB84 dB83 dB-80 dB84 dB
Solid cab--opt.-opt.opt.opt.opt.opt.opt.
Diff. lock--differential lock with cogsopt.opt.opt.opt.opt.opt.differential lock with cogs
Creeper gear--xopt.opt.opt.opt.opt.opt.opt.
Max. speed ---31.6 km/h29.1 km/h29.1 km/h-28.8 km/h30 km/h30/37 km/h
