Case IH 956-1056 XL
Manufacturer
Models
Case IH 956 XL, Case IH 956 XL, Case IH 1056 XL, Case IH 1056 XL
Years
1985-92
Info
Also, the 956 and 1056 received the Case IH design in two stages (cf. 743-856). At first, only the color was changed, and the design was revised in the summer of 1986, at which time the four-wheel drive was also changed to a central driveshaft system and the transmission was changed to a pressure-lubricated type.
The power ratings listed in Finland remained 97 and 110 hp.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Case IH 956 XL | Case IH 956 XL | Case IH 1056 XL | Case IH 1056 XL |
|---|---|---|---|---|
| Options | ||||
| Manufacturer name | Case IH | Case IH | Case IH | Case IH |
| Imported to Finland | Yes | Yes | Yes | Yes |
| Years | 1985-86 | 1986-92 | 1985-86 | 1986-92 |
| First year sold | 1985 | 1986 | 1985 | 1986 |
| Last year sold | 1986 | 1992 | 1986 | 1992 |
| Engine model | D-358 | D-358 | D-358 | D-358 |
| Cyl/Turbo/Intercooler | 6 | 6 | 6 | 6 |
| Displacement | 5867 cm³ | 5867 cm³ | 5867 cm³ | 5867 cm³ |
| Bore x stroke | 98,4×128,5 mm | 98,4×128,5 mm | 98,4×128,5 mm | 98,4×128,5 mm |
| Rated power hp/rpm DIN | 95/2200 | 95/2200 | 105/2300 | 105/2300 |
| Rated power | 95 | 95 | 105 | 105 |
| Rated speed | 2200 | 2200 | 2300 | 2300 |
| Torque Nm/rpm DIN | 364/1400 | 364/1400 | 378/1400 | 378/1400 |
| Gears | 16+8 | 16+8 | 16+8 | 16+8 |
| Synchronized gears | 16+8 | 16+8 | 16+8 | 16+8 |
| Powershift gears | mech. | mech. | mech. | mech. |
| Speeds in km/h | 1,8-27,1 | 2,2-35,6 | 1,8-27,1 | 2,2-35,6 |
| Max. speed | 30 km/h | 39 km/h | 30 km/h | 39 km/h |
| Hydr. flow l/min | 43 l/min | 43 l/min | 45 l/min | 45 l/min |
| Hydraulic pressure | 167 bar | 167 bar | 167 bar | 167 bar |
| Lift controls | mech. | mech. | mech. | mech. |
| Lift capacity | 4460 kg | 4460 kg | 4460 kg | 4460 kg |
| PTO speeds | 540/1000/ajo | 540/1000/ajo | 540/1000/ajo | 540/1000/ajo |
| Brakes | wet disc | wet disc | wet disc | wet disc |
| Steering | hydrost. | hydrost. | hydrost. | hydrost. |
| Turning circle m 2WD | 10.1 | 10.1 | 10.1 | 10.1 |
| Turning circle m 4WD | 10.1 | 10.1 | 10.64 | 10.1 |
| Front tyres 2WD | 7,50-20 | 7,50-20 | 7,50-20 | 7,50-20 |
| Front tyres 4WD | 12.4R28 | 12.4R28 | 13.6R28 | 13.6R28 |
| Rear tyres 2WD | 16,9R38 | 16,9R38 | 18,4R38 | 18,4R38 |
| Rear tyres 4WD | 16.9R38 | 16.9R38 | 18.4R38 | 18.4R38 |
| Weight 2WD | 4290 kg | 4290 kg | 4370 kg | 4370 kg |
| Weight 4WD | 4670 kg | 4670 kg | 4750 kg | 4750 kg |
| Height with cab | 277 cm | 277 cm | 280 cm | 280 cm |
| Length (2WD/4WD) | 419/426 cm | 419/426 cm | 419/426 cm | 419/426 cm |
| Wheelbase (2WD/4WD) | 263/259 cm | 263/264 cm | 263/259 cm | 263/264 cm |
| Fuel tank | 140 l | 140 l | 140 l | 140 l |
| Cab noise level | 83 dB | 83 dB | 82 dB | 82 dB |
| Solid cab | x | x | x | x |
| Diff. lock | friction lock | friction lock | friction lock | friction lock |
| Creeper gear | opt. | opt. | opt. | opt. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
