Belarus Progress 505/525, 805/825, Agross 506/526, 806/826

84BelarusProgress825 2
83BelarusProgressohjaamo
89Belarus826Agross
88BelarusAgross826ohjaamo
84BelarusProgress825 2
83BelarusProgressohjaamo
89Belarus826Agross
88BelarusAgross826ohjaamo
Manufacturer
Models
Belarus Progress 505/525, Belarus Progress 805/825, Belarus Progress 805/825 Turbo, Belarus Agross 506/526, Belarus Agross 526 HX, Belarus Agross 806/826, Belarus Agross 806/826 Turbo
Years
1983-98
Info

In the autumn of 1983, Maaseudun Kone's Progress cab and silver coloring were introduced also to the larger Belarus models. At the same time, especially in the larger model, several changes were made, which resulted in the model number increasing by five steps. The power rose to 85 horsepower, and the transmission ratios were altered so that the top speed increased close to forty km/h. The lifting capacity was also higher than before.

Here, only the models sold in Finland and Sweden are presented, where the 100 hp model was equipped with a turbo installed in Finland. At the same time, the factory also introduced more powerful models (MTZ-100, 1060/1062), which featured a 24+8 transmission as well as smaller series direct injection versions 570/572. Other versions than those presented here also came to Finland through unofficial importers.

In 1988 and 1989, models named Agrossi, equipped with Soviet-made cabs, were again brought to the Finnish market; these soon supplanted the more expensive Progress models. Agrossi could be optionally equipped with an electronic hydraulic system for the three-point hitch, developed by the Danish Belarus importer. The 526 HX, equipped with a direct injection diesel engine and a reduction fast gear, entered the Finnish market in 1990. Its gear shifting was modified to follow the normal H-pattern.

In 1994, the engine was improved, including replacement of the injection pump. At the same time, the brakes were enlarged and a domestic valve block for the external hydraulics was installed in Finland.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelBelarus Progress 505/525Belarus Progress 805/825Belarus Progress 805/825 TurboBelarus Agross 506/526Belarus Agross 526 HXBelarus Agross 806/826Belarus Agross 806/826 Turbo
Manufacturer nameBelarusBelarusBelarusBelarusBelarusBelarusBelarus
Imported to FinlandYesYesYesYesYesYesYes
Years1983-901983-901983-901989-961990-981988-981988-98
Engine modelD-60D-240/243D-240/243D-60D-242D-240/243D-240/243
Cyl/Turbo/Intercooler444T4444T
Displacement4750 cm³4750 cm³4750 cm³4750 cm³4750 cm³4750 cm³4750 cm³
Bore x stroke110×125 mm110×125 mm110×125 mm110×125 mm110×125 mm110×125 mm110×125 mm
Rated power65/1800 hp DIN/rpm85/2200 hp DIN/rpm100/2200 hp DIN/rpm65/1950 hp DIN/rpm72/1950 hp DIN/rpm85/2200 hp DIN/rpm100/2200 hp DIN/rpm
Torque-------
Gears9+218+418+49+218+418+418+4
Speeds in km/h2,0-27,31,9-38,71,9-38,72,1-31,41,5-34,31,8-38,71,8-38,7
Hydr. flow l/min50 l/min50 l/min50 l/min50 l/min50 l/min50 l/min50 l/min
Hydraulic pressure175 bar175 bar175 bar175 bar175 bar175 bar175 bar
Lift controlsmech.mech.mech.mech. (elec.)mech. (elec.)mech. (elec.)mech. (elec.)
Lift capacity2750 kg3200 kg3200 kg2750 kg3200 kg3200 kg3200 kg
PTO speeds540/ajov.540/1000/ajo540/1000/ajo540/ajov.540/ajov.540/1000/ajo540/1000/ajo
Brakesdisc brakesdisc brakesdisc brakesdisc brakesdisc brakesdisc brakesdisc brakes
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 2WD8888-88
Turning circle m 4WD10.510.510.510.510.510.510.5
Front tyres 2WD7,50-207,50-207,50-209,00-20-9,00-209,00-20
Front tyres 4WD11.2-2011.2-2011.2-2011.2-2011.2-2011.2-2011.2-20
Rear tyres 2WD15,5-3815,5-3815,5-3815,5-38-15,5-3815,5-38
Rear tyres 4WD15.5-3815.5-3815.5-3815.5-3815.5-3815.5-3815.5-38
Weight 2WD3390 kg3510 kg3510 kg3620 kg-3630 kg-
Weight 4WD3670 kg3790 kg3790 kg3840 kg3900 kg3900 kg3900 kg
Height with cab265/267 cm265/267 cm265/267 cm281 cm281 cm281 cm281 cm
Length (2WD/4WD)382/385 cm382/385 cm382/385 cm402/404 cm404 cm404 cm404 cm
Wheelbase (2WD/4WD)236 cm237/245 cm237/245 cm237/245 cm245 cm245 cm245 cm
Fuel tank110 l110 l110 l110 l110 l110 l110 l
Cab noise level84.5 dB84 dB83 dB85 dB85 dB85 dB85 dB
Solid cabxxxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lockfriction lock
Powershift gears-mech.mech.-mech.mech.mech.
Autom. differential locks-xxxxxx
