Sampo 2045-2065
The pioneer of the completely new series of combine harvesters was the 2055, introduced in the fall of 1989. A year later, the 2045, 2050, and 2060 models followed. The biggest differences within the lineup were in engine power, grain tank height, and the width of the cutting platform. All models featured a 111-centimeter threshing drum and four threshing concaves.
In the first years, improvements were made to the 2000 series, including the transmission, drive shaft bearing, straw walker, and feed conveyor, which was changed to a three-chain type. For the year 1995, the 2065 was added to the lineup, fitted with five threshing concaves within the same concave space width. In some countries, the 2060 model, which had been discontinued in Finland, continued and was also equipped with five threshing concaves. Other updates for the 1995 season included a revised sliding clutch structure on the platform and a reinforced straw walker.
This is an automated translation. Please report any issues in the translation.
| Model | SR 2045 | SR 2050 | SR 2050 | SR 2055 | SR 2055 | SR 2060 | SR 2065 |
|---|---|---|---|---|---|---|---|
| Options | |||||||
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1990-96 | 1990-92 | 1992-96 | 1989-90 | 1990-96 | 1990-94 | 1994-96 |
| First year sold | 1990 | 1990 | 1992 | 1989 | 1990 | 1990 | 1994 |
| Last year sold | 1996 | 1992 | 1996 | 1990 | 1996 | 1994 | 1996 |
| Power | 84 | 95 | 100 | 120 | 120 | 140 | 140 |
| Engine | Valmet | Valmet | Valmet | Valmet | Valmet | Valmet | Valmet |
| Engine type | - | - | - | 611 DL | 611 DL | 611 DL | - |
| Displacement | 4400 cm³ | 4400 cm³ | 4400 cm³ | 6600 cm³ | 6600 cm³ | 6600 cm³ | 6600 cm³ |
| Cyl/turbo | 4 | 4 T | 4 T | 6 | 6 | 6 T | 6 T |
| Power hp DIN | 84 | 95 | 100 | 120 | 120 | 140 | 140 |
| Fuel tank | 200 l | 200 l | 200 l | 180 l | 200 l | 200 l | 200 l |
| Transmission | mech. | mech. | mech. | hydr. | hydr. | hydr. | hydr. |
| Gears | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Speed min-max. | 1,7-25 km/h | 1,7-25 km/h | 1,7-25 km/h | 0-26 km/h | 0-26 km/h | 0-26 km/h | 0-24 km/h |
| Cutting width | 310 cm | 345 cm | 345 cm | 420 cm | 420 cm | 420 cm | 420 cm |
| Cutting width, alternative | 345 cm | - | - | 345 cm | 345 cm | - | - |
| Reel diameter | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm |
| Header length | 51 cm | 51 cm | 51 cm | 51 cm | 51 cm | 51 cm | 51 cm |
| Threshing cyl. diameter | 50 cm | 50 cm | 50 cm | 50 cm | 50 cm | 50 cm | 50 cm |
| Threshing cyl. width | 111 cm | 111 cm | 111 cm | 111 cm | 111 cm | 111 cm | 111 cm |
| Number of straw walkers | 4 | 4 | 4 | 4 | 4 | 4 | 5 |
| Area of walkers | 460 dm² | 460 dm² | 460 dm² | 460 dm² | 460 dm² | 460 dm² | 460 dm² |
| Lenght of walkers | 410 cm | 410 cm | 410 cm | 410 cm | 410 cm | 410 cm | 410 cm |
| Straw shieve | 207 dm² | 207 dm² | 207 dm² | 207 dm² | 207 dm² | 207 dm² | 207 dm² |
| Bottom shieve | 133 dm² | 133 dm² | 133 dm² | 133 dm² | 133 dm² | 133 dm² | 133 dm² |
| Total screening area | 340 | 340 | 340 | 340 | 340 | 340 | 340 |
| Overall lenght | 850 cm | 850 cm | 850 cm | 850 cm | 850 cm | 850 cm | 850 cm |
| Overall width | 335 cm | 370 cm | 370 cm | 453 cm | 453 cm | 453 cm | 453 cm |
| Width without header | 300 cm | 300 cm | 300 cm | 300 cm | 300 cm | 310 cm | 324 cm |
| Height with cabin | 350 cm | 350 cm | 350 cm | 350 cm | 350 cm | 350 cm | 350 cm |
| Weight with cabin | 5700 kg | 6000 kg | 6000 kg | 6150 kg | 6300 kg | 7000 kg | 7100 kg |
| Grain tank | 33 hl | 33 hl | 33 hl | 33 hl | 37 hl | 42 hl | 42 hl |
| Unl. height | 330 cm | 330 cm | 330 cm | 330 cm | 330 cm | 340 cm | 340 cm |
| Tyres front (Finland) | 16.9R34 | 18.4R34 | 18.4R34 | 18.4R34 | 18.4R34 | 23.1R26 | 600/65R34 |
| Tyres front, alternative | - | - | - | - | - | 600/65R34 | - |
| Tyres rear (Finland) | 11.2R20 | 11.2R20 | 12.4R20 | 11.2R20 | 12.4R20 | 12.4R20 | 375/75R20 |
| Tyres rear, alternative | - | 12.4R20 | - | - | - | 375/75R20 | - |
| Reel forward/backw. adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Reel speed adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Threshing cyl. speed adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Bottom sieve | convertible | convertible | convertible | convertible | convertible | convertible | convertible |
| Brakes | mech. shoe | mech. shoe | mech. shoe | mech. shoe | mech. shoe | mech. shoe | mech. shoe |
| Reverser | - | - | - | - | - | - | x |
| Heating | x | x | x | x | x | x | x |
| Type of cutting platform floating | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper |
