Sampo 2035-2085 TS

With the Optima series, the combine harvester's equipment could be selected more freely than before. The model designation 2050 was discontinued; a comparable harvester could now be customized from the 2045 model. The belt drive of the feed auger, which had caused problems in the 2045/2050 models, was renewed. The largest model became the 2075 TS, equipped with an after-threshing drum.
For 1998, the smaller model range (2020/2025) was replaced by the 2035, which had shorter threshing bars than the 2045 and a reduced standard equipment package. In all sheet metal constructions, 40% stronger steel was adopted. Starting from the 3,700-liter grain tank, the feed auger drive was operated via an angular gearbox.
For 1999, the 2035 also became available with hydrostatic drive, and a 185-horsepower 2085 TS was introduced at the top of the range. At the same time, the gearbox was reinforced.
This is an automated translation. Please report any issues in the translation.
| Model | SR 2035 Optima | SR 2045 Optima | SR 2055 Optima | SR 2065 Optima | SR 2075 TS Optima | SR 2075 TS Optima | SR 2085 TS Optima |
|---|---|---|---|---|---|---|---|
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1997-99 | 1996-99 | 1996-99 | 1996-99 | 1996-97 | 1997-99 | 1998-99 |
| Engine | Valmet | Valmet | Valmet | Valmet | Valmet | Valmet | Valmet |
| Engine type | 420 | 420 | 620 | 620 | 620 | 620 | 620 |
| Displacement | 4400 cm³ | 4400 cm³ | 6600 cm³ | 6600 cm³ | 6600 cm³ | 6600 cm³ | 6600 cm³ |
| Cyl/turbo | 4 | 4 T | 6 | 6 T | 6 T | 6 T | 6 T |
| Power | 87 hp DIN | 100 hp DIN | 120 hp DIN | 140 hp DIN | 185 hp DIN | 160 hp DIN | 185 hp DIN |
| Fuel tank | 200 l | 200 l | 200 l | 200 l | 250 l | 250 l | 250 l |
| Transmission | mech. | mech. (hydr.) | hydr. | hydr. | hydr. | hydr. | hydr. |
| Gears | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Speed min-max. | 1,8-25 km/h | 1,7-24,8 km/h | 0-26 km/h | 0-26 km/h | 0-23,7 km/h | 0-23,7 km/h | 0-25 km/h |
| Cutting width | 310 cm | 345 cm | 345 cm | 420 cm | 450 cm | 450 cm | 450 cm |
| Cutting width, alternative | 270, 345 cm | 310 cm | 420 cm | 390, 450 cm | 390, 420 cm | 390, 420 cm | 390, 420 cm |
| Reel diameter | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm | 105 cm |
| Header length | 51 cm | 51 cm | 51 cm | 51 cm | 51 cm | 51 cm | 51 cm |
| Threshing cyl. diameter | 50 cm | 50 cm | 50 cm | 50 cm | 50 cm | 50 cm | 50 cm |
| Threshing cyl. width | 111 cm | 111 cm | 111 cm | 111 cm | 111 cm | 111 cm | 111 cm |
| Number of straw walkers | 4 | 4 | 4 | 4 | 5 | 5 | 5 |
| Area of walkers | 426 dm² | 460 dm² | 460 dm² | 460 dm² | 460 dm² | 460 dm² | 460 dm² |
| Lenght of walkers | 380 cm | 410 cm | 410 cm | 410 cm | 410 cm | 410 cm | 410 cm |
| Straw shieve | 187 dm² | 207 dm² | 207 dm² | 207 dm² | 207 dm² | 207 dm² | 207 dm² |
| Bottom shieve | 113 dm² | 133 dm² | 133 dm² | 133 dm² | 133 dm² | 133 dm² | 133 dm² |
| Total screening area | 300 | 340 | 340 | 340 | 340 | 340 | 340 |
| Overall lenght | 825 cm | 850 cm | 850 cm | 850 cm | 993 cm | 993 cm | 993 cm |
| Overall width | 343 cm | 378 cm | 378 cm | 453 cm | 483 cm | 483 cm | 483 cm |
| Width without header | 300 cm | 300 cm | 300 cm | 324 cm | 324 cm | 324 cm | 324 cm |
| Height with cabin | 350 cm | 350 cm | 350 cm | 350 cm | 350 cm | 350 cm | 350 cm |
| Weight with cabin | 5700 kg | 6000 kg | 6600 kg | 7100 kg | 7500 kg | 7500 kg | 7500 kg |
| Grain tank | 30 hl | 33 hl | 37 hl | 42 hl | 46 hl | 46 hl | 46 hl |
| Unl. height | 330 cm | 330 cm | 330 cm | 340 cm | 340 cm | 340 cm | 340 cm |
| Tyres front (Finland) | 16.9R34 | 16.9R34 | 18.4R34 | 600/65R34 | 600/65R34 | 600/65R34 | 600/65R34 |
| Tyres front, alternative | 600/65R34 | 600/65R34 | 750/65R26 | 750/65R26 | 750/65R26 | 750/65R26 | 750/65R26 |
| Tyres rear (Finland) | 11.2R20 | 11.2R20 | 12.4R20 | 375/75R20 | 375/75R20 | 375/75R20 | 375/75R20 |
| Tyres rear, alternative | 375/75R20 | 375/75R20 | 375/75R20 | 550/45-22.5 | 550/45-22.5 | 550/45-22.5 | 550/45-22.5 |
| Reel forward/backw. adjustment | mech. | elec. | elec. | elec. | elec. | elec. | elec. |
| Reel speed adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Threshing cyl. speed adjustment | elec. | elec. | elec. | elec. | elec. | elec. | elec. |
| Bottom sieve | convertible | convertible | convertible | convertible | convertible | convertible | convertible |
| Brakes | mech. shoe | mech. shoe | mech. shoe | mech. shoe | mech. shoe | mech. shoe | mech. shoe |
| Heating | x | x | x | x | x | x | x |
| Type of cutting platform floating | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper |
| Alternative hp | - | 115 hp | - | - | - | - | - |
| Reverser | - | x | x | x | x | x | x |
| Air conditioning | - | - | - | x | x | x | x |
| 2. cyl. diameter | - | - | - | - | 40 cm | 40 cm | 40 cm |
