White 100-185

Manufacturer
Models
White 100, White 120, White 140, White 160, White 185
Years
1987-90
Info

Texas Instruments sold White Farm Equipment’s tractor production to Allied Products, a company that owned the agricultural machinery manufacturer New Idea. The combines ended up with MF (Massey Ferguson). The White-New Idea tractor brand returned from WFE to White in 1987. In 1987, the main tractor lineup was renewed, and the model designations became White 100, 120, 140, 160, and 185. The designations roughly indicated the power take-off horsepower. The engines were changed to Cummins. The transmission continued to be the age-old unsynchronized 18+6, which had a 3-speed hydraulic powershift. Lifting capacity was increased. Even the smaller models now had oil-immersed disc brakes. The 100-140 four-wheel-drive models had a significantly longer wheelbase than before and featured a limited-slip differential for the first time. The middle model was now based on the technology of the smaller models, unlike before. Only the 160 had a larger engine and a dual-disc clutch. The cab was similar to the previous one: quiet but simple. As an optional extra, the FieldFacts multifunction display could be equipped with a wheel slip monitor.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelWhite 100White 120White 140White 160White 185
Manufacturer nameWhiteWhiteWhiteWhiteWhite
Imported to FinlandNoNoNoNoNo
Years1987-901987-901987-901987-901987-90
Engine modelB6-590B6-590B6-590C6T-830C6T-830
Cyl/Turbo/Intercooler66T6TA6T6TA
Displacement5883 cm³5883 cm³5883 cm³8277 cm³8277 cm³
Bore x stroke102×120 mm98,4×127 mm98,4×127 mm114×135,1 mm114×135,1 mm
Rated power-----
Gears18+618+618+618+618+6
Powershift gears3-step3-step3-step3-step3-step
Speeds in km/h2,4-28,22,6-30,22,8-29,32,9-29,32,9-29,3
Hydr. flow l/min71.9 l/min83.3 l/min83.3 l/min83.3 l/min83.3 l/min
Hydraulic pressure155 bar155 bar155 bar158 bar158 bar
Lift controlsmech.mech.mech.mech.mech.
Lift capacity3261 kg3261 kg3261 kg3191 kg3191 kg
PTO speeds540/1000540/1000540/100010001000
Brakeswet discwet discwet discwet discwet disc
Steeringhydrost.hydrost.hydrost.hydrost.hydrost.
Turning circle m 2WD7,16 jarruilla7,16 jarruilla8,46 jarruilla7,92 jarrulla7,92 jarrulla
Turning circle m 4WD7,78 jarruilla7,78 jarruilla8,92 jarruilla8,98 jarrulla8,98 jarrulla
Front tyres 2WD9.5L1510.00-1611.00-1611.00-1614L-16
Front tyres 4WD14.9-2814.9-2814.9-2814.9-3014.9-30
Rear tyres 2WD18.4R3818.4R3818.4R3820.8R3820.8R38
Rear tyres 4WD18.4R3818.4R3818.4R3820.8R3820.8R38
Weight 2WD5400 kg5512 kg5625 kg5985 kg6120 kg
Weight 4WD5895 kg6007 kg6210 kg6660 kg6795 kg
Height with cab298/300 cm298/300 cm302/307 cm305/310 cm305/310 cm
Length (2WD/4WD)441/440 cm441/440 cm446 cm427 cm427 cm
Wheelbase (2WD/4WD)283/250 cm283/250 cm283/250 cm284/229 cm284/229 cm
Fuel tank220 l220 l243 l281 l281 l
Cab noise level77 dB77 dB75.5 dB76.5 dB76.5 dB
Solid cabxxxxx
Diff. lockfriction lockfriction lockfriction lockfriction lockfriction lock
Air conditioningxxxxx
