The Minneapolis-Moline Z was redesigned as the ZA in 1949. The engine had an increased stroke length. New features included a hydraulic lifting device. The wheels had grown to 38 inches. The steering shaft was still on the left side, but its height could now be adjusted. In addition to row-crop models, the lineup now also included a Standard version with a shorter wheelbase. Electric start with a 6-volt electrical system was now standard equipment.

In the ZB and UB models, the driver sat significantly higher than before; the reported heights of 188…200 cm to the steering wheel were remarkably tall at the time. The steering wheel was moved to the centerline, although the steering shaft still ran on the side. The clutch was now operated by a pedal. The optional power take-off was equipped with a separate clutch. The ignition system was 12 volts, and the cooling system was pressurized. Another new feature was disc brakes. The ZB and UB were always row-crop tractors, but one option was the ZBE/UBE with a wide-adjustable front axle.

This is an automated translation. Please report any issues in the translation.

Minneapolis-Moline ZAU

malli

hinta (sis. alv)

Series specifier

Manufacturer name

Model specifier

Imported to Finland

Years

Engine model

Cyl/Turbo/Intercooler

Displacement

Bore x stroke

Rated power

Max power

Torque

Gears

Creeper speeds

Synchronized gears

Powershift gears

Reverser

Speeds in km/h

Max. speed

Hydr. flow l/min

Hydraulic pressure

Lift controls

Lift capacity

PTO speeds

Brakes

Steering

Turning circle m 2WD

Turning circle m 4WD

Front tyres 2WD

Front tyres 4WD

Rear tyres 2WD

Rear tyres 4WD

Weight 2WD

Weight 4WD

Height with cab

Length (2WD/4WD)

Wheelbase (2WD/4WD)

Fuel tank

Cab noise level

Solid cab

Diff. lock

Autom. differential locks

Air suspension seat

Air conditioning

Trip computer

Creeper gear

sylinterien lukumäärä

iskutilavuus

iskusuhde

suurin vääntömomentti, nm

suurin vääntömomentti, r/min

vääntömomentin nousu

polttonesteen kulutus suurimman tehon pisteessä

kytkimen tyyppi

ajovoimanotto

nopeus eteenpäin moottorin nimellisnopeudella, pienin

nopeus eteenpäin moottorin nimellisnopeudella, suurin

jarrut

hydrauliikan suurin paine

hydrauliikan suurin tuotto

nostolaitehydrauliikan hallinta

ulkopuolinen hydrauliikka, venttiililohkoja

1-toimisia

2-toimisia

nostovoima (kn=100 kg)

hydrauliikan tyyppi

kääntöympyrän halkaisija ilman ohjausjarrua

eturenkaat

takarenkaat

kokonaismassa säiliöt täynnä vakiovarustein

etuakselipaino

taka-akselipaino

suurin korkeus (ohjaamon ylimpään kohtaan)

kokonaispituus

akseliväli

maavara, pienin

polttoainesäiliön tilavuus

korkein melutaso

etuakselin tasauspyörästön lukko

etunostolaite

etulokasuojat

ilmastointilaite

perävaunun jarruventtiili

ilmaistuin

ohjauksen tyyppi

Minneapolis-Moline ZAS

Minneapolis-Moline ZBU

Minneapolis-Moline UBU

Minneapolis-Moline ZA/ZB/UB

Etusivu

Ajoneuvot ja ympäristö

Huolto ja tekniikka

Lukijan idea

Maarakennus

Maatalous

Osastot

Metsä

Pääkirjoitus

Uutiset

Weteraani

Yritykset ja tapahtumat

Koneviesti

Lehdet

Konedata

Palvelut

Tilaa Koneviesti

Asiakaspalvelu

Jätä ilmoitus

Tilaa uutiskirje

Lähetä uutisvinkki

Lähetä palautetta

Lähetä oikaisupyyntö

Toimituksen yhteystiedot

Mediamyynnin yhteystiedot

Ota yhteyttä

Send feedback

Welcome to the beta version of Koneviesti's new Konedata service! The service offers technical data for over 8000 tractors and combines. We are actively developing the service, so we appreciate your feedback.

Give feedback

Model	Minneapolis-Moline ZAU	Minneapolis-Moline ZAS	Minneapolis-Moline ZBU	Minneapolis-Moline UBU
Manufacturer name	Minneapolis-Moline	Minneapolis-Moline	Minneapolis-Moline	Minneapolis-Moline
Imported to Finland	No	No	No	No
Years	1949-53	1949-53	1953-55	1953-55
Engine model	2068-4	2068-4	2068-4	283A
Cyl/Turbo/Intercooler	4	4	4	4
Displacement	3382 cm³	3382 cm³	3382 cm³	4649 cm³
Bore x stroke	92,1×127 mm	92,1×127 mm	92,1×127 mm	108×127 mm
Rated power	-	-	-	-
Gears	5+1	5+1	5+1	5+1
Speeds in km/h	3,9-21,1	3,9-21,1	3,9-21,1	3,4-24,3
Lift controls	mech.	mech.	mech.	mech.
PTO speeds	(615)	(615)	(615)	(585)
Brakes	drum brakes	drum brakes	disc brakes	disc brakes
Steering	mech.	mech.	mech.	mech.
Turning circle m 2WD	4.88	7.32	4.06	5.18
Front tyres 2WD	5.50-16	5.50-16	5.50-16	6.00-16
Rear tyres 2WD	11-38	11-38	11-38	12-38
Weight 2WD	(1701) kg	(1706) kg	(1678) kg	(2404) kg
Height with cab	(185) cm	(165) cm	(188) cm	(200) cm
Length (2WD/4WD)	328 cm	315 cm	321 cm	338 cm
Wheelbase (2WD/4WD)	211 cm	185 cm	208 cm	224 cm
Fuel tank	72 l	72 l	72 l	79 l
