Ford's largest model range in the early 1970s was represented by the American-origin 8000 and 9000. The engines were 6.6 liters, used in numerous later models as well, and a Dual Power quick-shift transmission was available as an option. Other features included a 13″ ceramic clutch, draft arm sensing, and hydrostatic steering. The tractors were available with both long and short wheelbases, as well as front wheels mounted side-by-side under the frame. The powertrain in these models was entirely unique, but the rear axle was partially reinforced and taken from the 5000 series.
The 8000 was introduced in Europe at the end of 1968, with the turbocharged 9000 arriving a year later. The differences between the models were minimal. In Europe, the cab used was the Swedish Hara (lower photo).
This is an automated translation. Please report any issues in the translation.
| Model | Ford 8000 | Ford 9000 |
|---|---|---|
| Manufacturer name | Ford | Ford |
| Imported to Finland | No | No |
| Years | 1968-72 | 1969-72 |
| Engine model | 401 | 401 |
| Cyl/Turbo/Intercooler | 6 | 6T |
| Displacement | 6578 cm³ | 6578 cm³ |
| Bore x stroke | 112×112 mm | 112×112 mm |
| Rated power | 110/2300 hp DIN/rpm | 140/2300 hp DIN/rpm |
| Torque | - | - |
| Gears | 8+2 | 8+2 |
| Powershift gears | opt. | opt. |
| Speeds in km/h | 2,9-27,8 | 3,0-28,3 |
| Max. speed | 2,5-29,6 DP km/h | - |
| Hydr. flow l/min | 45/60 l/min | 60.5 l/min |
| Hydraulic pressure | 179 bar | 179 bar |
| Lift controls | mech. | mech. |
| Lift capacity | 3200 kg | - |
| PTO speeds | 540/1000 | 1000 |
| Brakes | wet disc | wet disc |
| Steering | hydrost. | hydrost. |
| Turning circle m 2WD | 7,92/9,14 | 7,92/9,14 |
| Front tyres 2WD | 10,00-16 | 10,00-16 |
| Rear tyres 2WD | 18,4-38 | 18,4-38 |
| Weight 2WD | 4760 kg | (4570) kg |
| Height with cab | 295 cm | - |
| Length (2WD/4WD) | 367/392 cm | - |
| Wheelbase (2WD/4WD) | 232/274 cm | 232/274 cm |
| Fuel tank | 163 l | 163 l |
| Cab noise level | 90 dB | 90 dB |
| Solid cab | x | x |
