John Deere 940 – 955
Manufacturer
Models
John Deere 940, John Deere 945, John Deere 945, John Deere 952, John Deere 950, John Deere 955, John Deere 955
Years
1972-83
Info
The new JD 900 series combines were introduced for the year 1973. The most significant innovation was the patented use of walkers. The headers were also new. The controls had been significantly improved.
The 1976 model lineup included many improvements: engine power increased, the drive belts had automatic tensioning, the grain tanks were larger than before, the construction of the walkers was renewed, and the sieving area was increased. A new feature was the Cross-Shaker straw walker agitator.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | John Deere 940 | John Deere 945 | John Deere 945 | John Deere 952 | John Deere 950 | John Deere 955 | John Deere 955 |
|---|---|---|---|---|---|---|---|
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1972-75 | 1975-77 | 1977-79 | 1977-83 | 1972-75 | 1975-77 | 1977-83 |
| Engine | JD | JD | JD | JD | JD | JD | JD |
| Engine type | 4239 DZ01 | 4239 TZ01 | 4239 TZ01 | 4239 TZ01 | 6329 DZ07 | 6329 DZ02 | 6329 DZ02 |
| Displacement | 3920 cm³ | 3920 cm³ | 3920 cm³ | 3920 cm³ | 5390 cm³ | 5390 cm³ | 5390 cm³ |
| Cyl/turbo | 4 | 4 T | 4 T | 4 T | 6 | 6 | 6 |
| Power | 75 hp DIN | 85 hp DIN | 85 hp DIN | 85 hp DIN | 100 SAE hp DIN | 105 hp DIN | 105 hp DIN |
| Fuel tank | 105 l | 175 l | 175 l | 175 l | 175 l | 175 l | 175 l |
| Transmission | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Gears | 3 | 3 | 3 | 3 | 3 | 3 | 3 (4) |
| Speed min-max. | 1,0-19,2 km/h | 1,1-19,1 km/h | 1,1-19,1 km/h | 1,1-19,1 km/h | 1,0-20,0 km/h | 1,0-20,0 km/h | 1,0-20,0 km/h |
| Cutting width | 305 cm | 305 cm | 305 cm | 305 cm | 305 cm | 305 cm | 365 cm |
| Reel diameter | 110 cm | 110 cm | 110 cm | 110 cm | 110 cm | 110 cm | 110 cm |
| Header length | 37 cm | 37 cm | 37 cm | 37 cm | 37 cm | 37 cm | 37 cm |
| Threshing cyl. diameter | 61 cm | 61 cm | 61 cm | 61 cm | 61 cm | 61 cm | 61 cm |
| Threshing cyl. width | 78 cm | 78 cm | 78 cm | 104 cm | 104 cm | 104 cm | 104 cm |
| Number of straw walkers | 3 | 3 | 3 | 4 | 4 | 4 | 4 |
| Area of walkers | 214 dm² | 285 dm² | 285 dm² | 377 dm² | 352 dm² | 377 dm² | 377 dm² |
| Lenght of walkers | 274 cm | 365 cm | 365 cm | 365 cm | 341 cm | 365 cm | 365 cm |
| Straw shieve | 141 dm² | 141 dm² | 141 dm² | 165 dm² | 145 dm² | 165 dm² | 165 dm² |
| Bottom shieve | 108 dm² | 108 dm² | 108 dm² | 120 dm² | 102 dm² | 120 dm² | 120 dm² |
| Total screening area | 249 | 249 | 249 | 307 | 247 | 285 | 285 |
| Overall lenght | 788 cm | 920 cm | 920 cm | 906 cm | 790 cm | 906 cm | 906 cm |
| Width without header | 243 cm | 281 cm | 281 cm | 273 cm | 290 cm | 284 cm | 284 cm |
| Height without cabin | 298 cm | 330 cm | 330 cm | 317 cm | 315 cm | 330 cm | 330 cm |
| Weight without cabin | 5046 kg | 4200 kg | 4970 kg | 5340 kg | 5990 kg | 5450 kg | 6280 kg |
| Grain tank | 21.1 hl | 21.1 hl | 21.1 hl | 27.1 hl | 27.1 hl | 31 hl | 31 hl |
| Tyres front (Finland) | 18.4-26 | 18.4-26 | 18.4-26 | 18.4-26 | 18.4-30 | 18.4-30 | 18.4-30 |
| Tyres rear (Finland) | 10.5-18 | 10.5-18 | 10.5-18 | 10.5-18 | 10.5-18 | 10.5-18 | 10.5-18 |
| Reel forward/backw. adjustment | mech. | mech. | mech. | mech. | mech. | mech. | mech. |
| Reel speed adjustment | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin |
| Threshing cyl. speed adjustment | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin | adj, in cabin |
| Bottom sieve | adj. | adj. | adj. | adj. | adj. | adj. | adj. |
| Brakes | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc | wet disc |
| Type of cutting platform floating | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper | gas damper |
| Alternative hp | - | 75 hp | 75 hp | - | - | - | - |
| Height with cabin | - | 357 cm | 357 cm | 357 cm | - | 356 cm | 356 cm |
| Cutting width, alternative | - | - | 365 cm | 365 cm | 365 cm | 365 cm | 305, 425 cm |
| Overall width | - | - | 325 cm | 325 cm | - | - | 385 cm |
| Tyres rear, alternative | - | - | - | 7.50-16 | - | - | 7.50-16 |
| Unl. height | - | - | - | - | 306 cm | - | - |
| Tyres front, alternative | - | - | - | - | - | - | 18.4-26 |
