<p>The JD 1100 series returned to production in Brazil. A large part of the components came from other JD factories, including the 300-series cutting platform from the USA. Only the 1170 model was imported to Europe. In the USA, models 1165 and 1175 were also available for sale. The 1170 featured traditional combine harvester technology, but the equipment was somewhat more extensive than in the earlier 1100 series harvesters.</p>
<p>This is an automated translation. Please report any issues in the translation.</p>


The JD 1100 series returned to production in Brazil. A large part of the components came from other JD factories, including the 300-series cutting platform from the USA. Only the 1170 model was imported to Europe. In the USA, models 1165 and 1175 were also available for sale. The 1170 featured traditional combine harvester technology, but the equipment was somewhat more extensive than in the earlier 1100 series harvesters.

This is an automated translation. Please report any issues in the translation.

John Deere 1170

Malli

Hinta (sis. alv)

Imported to Finland

Years

First year sold

Last year sold

Power

Power speed

Engine

Engine type

Moottorin merkki ja malli

Turbo

Teho

Iskutilavuus

Sylinterien lukumäärä

Moottorin sijainti

Polttoainesäiliön tilavuus

Ajovoimansiirron tyyppi

Nopeusalueiden lukumäärä

Neliveto

Työleveys

Leikkuuleveys

Leikkuupöydän korkeuden säätö

Syöttöruuvin harjan etäisyys terän sormien kärjestä

Terän korkeus, minimi

Terän korkeus, maksimi

Leikkuupöydän korkeuden osoitin

Säätö korkeussuunnassa

Säätö pituussuunnassa

Nopeuden säätö

Puintikelojen lukumäärä

Varstojen lukumäärä

Kelojen leveys

Kelojen nopeus, maksimi

Kelojen nopeuden säätötapa

Varstasiltojen lukumäärä

Siltojen pituudet (varstojen ulkoreunasta mitaten)

Puintivälin säätö

Puintivälin toteaminen ja mittaus

Kohlimien lukumäärä

Kohlimien leveys

Kohlimien pituus

Kohlimien pinta-ala

Ruumenpinta-ala

Siemenpinta-ala

Eturaideväli

Akseliväli

Pituus kuljetusasennossa ilman pöytää

Korkeus (ylimp. kiint. pisteeseen)

Leveys, työasennossa

Leveys, kuljetusasennossa

Maavara koneen alla (minimi)

Viljasäiliön tilavuus

Viljasäiliön tilavuus lisälaidoin

Paino työkunnossa (polttoainesäiliöt täynnä)

Jarrut

Laonnostimien lukumäärä

Ruumenseulan tyyppi

Työvalojen lukumäärä

Työvalojen tyyppi

Teho, kW/Suurimman tehon kierrosluku, r/min

Suurimman tehon kierrosluku

Iskutilavuus, cm3/Sylinterien lukumäärä, kpl

Nopeus, km/h

Työleveys (jakol. kärjestä mitattuna), cm/Leikkuuleveys, cm

Terän alin...ylin taso (korkeus maasta), cm

Laonnostokelan säätöalue, r/min

Puintikela 1 halkaisija

Puintikela 2 halkaisija

Puintikela 3 halkaisija

Puintikelojen halkaisijat, cm

Puintikelojen nopeuden säätö

Varstojen 1 tehollinen pinta-ala (kaareva pituus x kelan leveys)

Varstojen 2 tehollinen pinta-ala (kaareva pituus x kelan leveys)

Varstojen 3 tehollinen pinta-ala (kaareva pituus x kelan leveys)

Varstojen teholliset pinta-alat (kaareva pit. x kelan lev.), dm2

Kohlintilan leveys x kohlinten pituus, cm

Renkaat edessä

Renkaat takana

Displacement

Esipuhdistaja

Cyl/turbo

Läpimitta (piikk.kärk.)

Power hp DIN

Power hp ISO

Alternative hp

Fuel tank

Transmission

Gears

Speed min-max.

Cutting width

Cutting width, alternative

Myynti

Takaraideväli, cm

Reel diameter

Header length

Threshing cyl. diameter

2. cyl. diameter

Threshing cyl. width

Number of straw walkers

Etusivu

Ajoneuvot ja ympäristö

Huolto ja tekniikka

Lukijan idea

Maarakennus

Maatalous

Osastot

Metsä

Pääkirjoitus

Uutiset

Weteraani

Yritykset ja tapahtumat

Lukijan kuvat

Koneviesti

Lehdet

Konedata

Palvelut

Tilaa Koneviesti

Asiakaspalvelu

Jätä ilmoitus

Tilaa uutiskirje

Lähetä uutisvinkki

Lähetä palautetta

Lähetä oikaisupyyntö

Toimituksen yhteystiedot

Mediamyynnin yhteystiedot

Ota yhteyttä

Subscribe

Paywall

Send feedback

Welcome to the beta version of Koneviesti's new Konedata service! The service offers technical data for over 8000 tractors and combines. We are actively developing the service, so we appreciate your feedback.

Give feedback

Model	John Deere 1170
Options
Imported to Finland	Yes
Years	1997-2001
First year sold	1997
Last year sold	2001
Power	170
Engine	JD
Engine type	6068 TC Q 50
Displacement	6788 cm³
Cyl/turbo	6 T
Power hp DIN	170
Fuel tank	400 l
Transmission	hydr.
Gears	3
Speed min-max.	0-25 km/h
Cutting width	425 cm
Cutting width, alternative	350, 485, 560 cm
Reel diameter	110 cm
Header length	37-47 cm
Threshing cyl. diameter	61 cm
Threshing cyl. width	130 cm
Number of straw walkers	5
Area of walkers	485 dm²
Lenght of walkers	375 cm
Straw shieve	228 dm²
Bottom shieve	187 dm²
Total screening area	460
Overall lenght	908 cm
Overall width	465 cm
Width without header	335 cm
Height with cabin	382 cm
Weight with cabin	9300 kg
Weight without header	8050 kg
Grain tank	60 hl
Unl. height	418 cm
Tyres front (Finland)	23.1R30
Tyres front, alternative	28.1-26
Tyres rear (Finland)	12.5/80-18
Tyres rear, alternative	400/55-22.5
Reel forward/backw. adjustment	hydr.
Reel speed adjustment	hydr.
Threshing cyl. speed adjustment	hydr.
Bottom sieve	adj.
Brakes	wet disc
Reverser	x
Air conditioning	x
Heating	x
Grain loss indicator	x
Slope levelling	x
Type of cutting platform floating	gas damper
