Ford 2910-4610 Mark II ja Mark III
Manufacturer
Models
Ford 2910 Mark II, Ford 3910 Mark II, Ford 4110 Mark II, Ford 4610 Mark II
Years
1985-89
Info
In 1985, the second generation of the 10-series was introduced. In the smaller models, changes were minor. However, the clutch disc had grown from 280 mm to 330 mm. The updated cab was called the S-cab instead of the previous LP. In Finland, the high roof section was standard. The production line also included a lower version, which, for example, was 233 cm high in the 4110 model.
In the years 1988-89, the smaller models were also known by the designation Mark III. The technical specifications correspond to those of the Mark II models. A digital instrument cluster was available as an optional extra.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Ford 2910 Mark II | Ford 3910 Mark II | Ford 4110 Mark II | Ford 4610 Mark II |
|---|---|---|---|---|
| Manufacturer name | Ford | Ford | Ford | Ford |
| Imported to Finland | No | Yes | Yes | Yes |
| Years | 1985-89 | 1985-89 | 1985-89 | 1985-89 |
| First year sold | 1985 | 1985 | 1985 | 1985 |
| Last year sold | 1989 | 1989 | 1989 | 1989 |
| Cyl/Turbo/Intercooler | 3 | 3 | 3 | 3 |
| Displacement | 2947 cm³ | 3147 cm³ | 3294 cm³ | 3294 cm³ |
| Bore x stroke | 107×107 mm | 112×107 mm | 112×112 mm | 112×112 mm |
| Rated power | 41/2000 hp DIN/rpm | 47/2000 hp DIN/rpm | 54/2200 hp DIN/rpm | 61/2200 hp DIN/rpm |
| Torque | - | - | - | - |
| Gears | 8+4 | 8+4 | 8+4 | 8+4 |
| Synchronized gears | 8+4 | 8+4 | 8+4 | 8+4 |
| Speeds in km/h | 2,7-29,4 | 2,9-31,4 | 2,8-30,2 | 2,8-31,1 |
| Hydr. flow l/min | 29 l/min | 29 l/min | 32 l/min | 32 l/min |
| Hydraulic pressure | 176 bar | 176 bar | 176 bar | 176 bar |
| Lift controls | mech. | mech. | mech. | mech. |
| Lift capacity | 1910 kg | 1910 kg | 1910 kg | 1910 kg |
| PTO speeds | 540 | 540 | 540 | 540 |
| Brakes | wet disc | wet disc | wet disc | wet disc |
| Steering | power | power | power | power |
| Turning circle m 2WD | 6.9 | 6.9 | 7 | 7 |
| Front tyres 2WD | 6,00-16 | 7,50-16 | 7,50-16 | 7,50-16 |
| Rear tyres 2WD | 12,4-32 | 12,4-32 | 12,4-36 | 13,6-36 |
| Weight 2WD | 2420 kg | 2550 kg | 2600 kg | 2650 kg |
| Height with cab | 241 cm | 244 cm | 249 cm | 251 cm |
| Length (2WD/4WD) | 342 cm | 342/366 cm | 342/366 cm | 352/369 cm |
| Wheelbase (2WD/4WD) | 197 cm | 197/214 cm | 197/214 cm | 215/214 cm |
| Fuel tank | 49 l | 49 l | 49 l | 60 l |
| Cab noise level | 84 dB | 84 dB | 84.5 dB | 83 dB |
| Solid cab | x | x | x | x |
| Turning circle m 4WD | - | 9.2 | 9.2 | 9.2 |
| Front tyres 4WD | - | 9.50-24 | 11.2-24 | 11.2-24 |
| Rear tyres 4WD | - | 14.9-28 | 13.6-36 | 13.6-36 |
| Weight 4WD | - | 2800 kg | 2850 kg | 2900 kg |
| Diff. lock | - | friction lock | friction lock | friction lock |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
