Massey Ferguson 3640 – 5650

04MF5650
91MF5650
04MF5650
91MF5650
Manufacturer
Models
MF 3640, MF 5650, MF 3640, MF 5650, MF 5650 Advanced
Years
1978-94
Info

MF's combine harvester production in Brazil began in 1973. The first models were the 210, 220, and 310, based on the 187 and 487. Even the smallest model could be equipped with a 4.5-meter cutting platform.

The Brazilian MF 3640 introduced in 1978 was most closely based on the European models 507 and 440. However, its threshing drums and sieves were longer than theirs. The engine was a 6-cylinder Perkins. In 1980, a 5-drum 5650 was introduced alongside it. In 1994, the design was modernized and the grain tanks were significantly enlarged. The 2004 Advanced model featured a modern, rounded-corner cab. Over the years, engine power increased and the range of equipment expanded. Available options include crawler undercarriage, four-wheel drive, automatic cutting platform height adjustment, and plastic reel tines. The 3640 and 5650 have been sold on all continents, and in 1989–1990, the 5650 was also manufactured in the USA.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelMF 3640MF 5650MF 3640MF 5650MF 5650 Advanced
Imported to FinlandNoNoNoNoNo
Years1978-941980-941994-20091994-20092009-
EnginePerkinsPerkinsPerkinsPerkinsSisuDiesel
Engine typeA6.354.4A6.354.41006-61006-6T620DSRL
Displacement5800 cm³5800 cm³5950 cm³5950 cm³6600 cm³
Cyl/turbo66T66T6TI
Power100 hp DIN136 hp DIN123 hp DIN168 hp DIN175 hp DIN
Transmissionmech.mech.mech.mech.mech.
Gears33333
Cutting width360 cm390 cm390 cm390 cm390 cm
Cutting width, alternative390, 420, 480 cm420, 480 cm420, 480 cm420-580 cm420-580 cm
Header length39(49-56) cm39(49-56) cm39(49-56) cm39(49-56) cm39(49-56) cm
Threshing cyl. diameter56 cm56 cm56 cm56 cm56 cm
Threshing cyl. width108 cm127 cm108 cm127 cm127 cm
Number of straw walkers45455
Area of walkers397 dm²476 dm²408 dm²489 dm²489 dm²
Lenght of walkers377 cm377 cm377 cm377 cm377 cm
Overall lenght810 cm850 cm818 cm850 cm850 cm
Weight without cabin6200 kg7100 kg6200 kg7100 kg7100 kg
Grain tank23 (34) hl25,5 (37,5) hl45 hl50 hl50 hl
Tyres front (Finland)18.4-2623.1-3018.4R2623.1R3023.1R30
Tyres rear (Finland)10.00-1610.00-1610.00-1610.00-1612.4R24
Reel forward/backw. adjustmentelec.elec.elec.elec.elec.
Reel speed adjustmenthydr.hydr.hydr.hydr.hydr.
Threshing cyl. speed adjustmentadj, in cabinadj, in cabinadj, in cabinadj, in cabinadj, in cabin
Bottom sieveconvertibleconvertibleconvertible (adj.)convertible (adj.)convertible (adj.)
Brakeshydr. expandinghydr. expandingwet discwet discwet disc
Type of cutting platform floatinggas dampergas dampergas dampergas dampergas damper
Fuel tank-320 l330 l330 l330 l
Straw shieve-197 dm²---
Bottom shieve-159 dm²---
Total screening area-394310360360
Width without header-346 cm314 cm332 cm332 cm
Height without cabin-375 cm338 cm347 cm347 cm
Height with cabin-375 cm-375 cm375 cm
Alternative hp--Cummins 130 hpCummins 175 hp-
Speed min-max.--1,5-27,9 km/h1,5-27,9 km/h1,5-27,9 km/h
Tyres front, alternative--23.1R2628.1R2628.1R26
Tyres rear, alternative--9.5R2412.4R24-
Floating cutting platform--xxx
Air conditioning----x
