Claas Lexion 405-430
Manufacturer
Models
Claas Lexion 405, Claas Lexion 410, Claas Lexion 410 Evol., Claas Lexion 415, Claas Lexion 420, Claas Lexion 420 Evol., Claas Lexion 430, Claas Lexion 430 Evol.
Years
1997-2003
Info
Small Lexion models replaced the Mega series, the production of which was still continued mainly for the Eastern European markets. Like the larger Lexion models, the 405-430 models also featured versatile electronics and an APS acceleration drum. The 2002 Evolution series was equipped with more powerful Caterpillar engines. In 2003, the series was replaced by the 500-series Lexions.
This is an automated translation. Please report any issues in the translation.
Technical data
| Model | Claas Lexion 405 | Claas Lexion 410 | Claas Lexion 410 Evol. | Claas Lexion 415 | Claas Lexion 420 | Claas Lexion 420 Evol. | Claas Lexion 430 | Claas Lexion 430 Evol. |
|---|---|---|---|---|---|---|---|---|
| Options | ||||||||
| Imported to Finland | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Years | 1997-2001 | 1997-2001 | 2001-03 | 1997-2001 | 1997-2001 | 2001-03 | 1997-2001 | 2001-03 |
| First year sold | 1997 | 1997 | 2001 | 1997 | 1997 | 2001 | 1997 | 2001 |
| Last year sold | 2001 | 2001 | 2003 | 2001 | 2001 | 2003 | 2001 | 2003 |
| Power | 170 | 190 | 196 | 200 | 220 | 220 | 240 | 260 |
| Engine | Perkins | Perkins | Caterpillar | Perkins | MB | Caterpillar | MB | Caterpillar |
| Engine type | 1006.60TW | 1006.60TA | 3126B | 1006.60TA | OM 366 LA | 3126B | OM 366 LA | 3126B |
| Displacement | 5980 cm³ | 5980 cm³ | 7200 cm³ | 5980 cm³ | 5958 cm³ | 7200 cm³ | 5958 cm³ | 7200 cm³ |
| Cyl/turbo | 6 T | 6 TI | 6 TI | 6 TI | 6 TI | 6 TI | 6 TI | 6 TI |
| Power hp DIN | 170 | 190 | 196 | 200 | 220 | 220 | 240 | 260 |
| Fuel tank | 500 l | 500 l | 500 l | 500 l | 500 l | 500 l | 500 l | 500 l |
| Transmission | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Gears | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Speed min-max. | 0-26,5 km/h | 0-26,5 km/h | 0-26,5 km/h | 0-26,5 km/h | 0-26,5 km/h | 0-26,5 km/h | 0-26,5 km/h | 0-26,5 km/h |
| Cutting width | 450 cm | 450 cm | 450 cm | 540 cm | 540 cm | 540 cm | 540 cm | 540 cm |
| Cutting width, alternative | 540 cm | 540 cm | 540 cm | 450, 600 cm | 450, 600 cm | 450, 600 cm | 450, 600 cm | 450, 600 cm |
| Reel diameter | 112 cm | 112 cm | 112 cm | 112 cm | 112 cm | 112 cm | 112 cm | 112 cm |
| Header length | 58 cm | 58 cm | 58 cm | 58 cm | 58 cm | 58 cm | 58 cm | 58 cm |
| Threshing cyl. diameter | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm | 60 cm |
| 2. cyl. diameter | 38 cm | 38 cm | 38 cm | 38 cm | 38 cm | 38 cm | 38 cm | 38 cm |
| Threshing cyl. width | 142 cm | 142 cm | 142 cm | 142 cm | 142 cm | 142 cm | 142 cm | 142 cm |
| Number of straw walkers | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Area of walkers | 554 dm² | 554 dm² | 625 dm² | 625 dm² | 625 dm² | 625 dm² | 625 dm² | 625 dm² |
| Lenght of walkers | 390 cm | 390 cm | 440 cm | 440 cm | 440 cm | 440 cm | 440 cm | 440 cm |
| Straw shieve | 240 dm² | 240 dm² | 240 dm² | - | - | - | - | - |
| Bottom shieve | 200 dm² | 200 dm² | 200 dm² | - | - | - | - | - |
| Total screening area | 440 | 440 | 440 | 480 | 480 | 480 | 480 | 480 |
| Overall lenght | 1064 cm | 1064 cm | 1064 cm | 1064 cm | 1064 cm | 1064 cm | 1064 cm | 1064 cm |
| Overall width | 500 cm | 500 cm | 500 cm | 590 cm | 590 cm | 590 cm | 590 cm | 590 cm |
| Width without header | 322 cm | 362 cm | 362 cm | 362 cm | 362 cm | 362 cm | 362 cm | 362 cm |
| Height with cabin | 385 cm | 385 cm | 387 cm | 385 cm | 385 cm | 385 cm | 385 cm | 385 cm |
| Weight with cabin | 13550 kg | 13550 kg | 13550 kg | - | - | - | - | - |
| Weight without header | 11000 kg | 11000 kg | 11000 kg | 11800 kg | 11800 kg | 11800 kg | 11800 kg | 11800 kg |
| Grain tank | 55 hl | 63 hl | 63 hl | 65 hl | 73 hl | 73 hl | 78 hl | 78 hl |
| Unl. height | 424 cm | 424 cm | 424 cm | 424 cm | 424 cm | 424 cm | 424 cm | 424 cm |
| Tyres front (Finland) | 650R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 | 800/65R32 |
| Tyres front, alternative | 800/65R32 | 73×44-32 | - | 73×44-32 | 73×44-32 | 20.8R42 | 73×44-32 | 20.8R42 |
| Tyres rear (Finland) | 500/70-24 | 600/55-26.5 | 600/55-26.5 | 600/55-26.5 | 600/55-26.5 | 600/55-26.5 | 600/55-26.5 | 600/55-26.5 |
| Tyres rear, alternative | 600/55-26.5 | 500/70-24 | 500/70-24 | 500/70-24 | 500/70-24 | 500/70-24 | 500/70-24 | 500/70-24 |
| Reel forward/backw. adjustment | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Reel speed adjustment | autom. | autom. | autom. | autom. | autom. | autom. | autom. | autom. |
| Threshing cyl. speed adjustment | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. | hydr. |
| Bottom sieve | adj. | adj. | adj. | adj. | adj. | adj. | adj. | adj. |
| Brakes | disc | disc | disc | disc | disc | disc | disc | disc |
| Reverser | x | x | x | x | x | x | x | x |
| Air conditioning | x | x | x | x | x | x | x | x |
| Grain loss indicator | x | x | x | x | x | x | x | x |
| Floating cutting platform | x | x | x | x | x | x | x | x |
| Slope levelling | - | - | - | - | - | - | - | Montana |
| Type of cutting platform floating | autom. | autom. | autom. | autom. | autom. | autom. | autom. | autom. |
The data has been collected primarily from brochures. In some cases, sources contain conflicting information. In such cases, we have attempted to select the most reliable information.
There is particularly significant variation in speed data, which varies depending on factors such as tire size. For tires, only the size most commonly used in Finland is listed.
Other changes during the model history have been addressed in the text section. For the front axle lock, the Finnish term "hammaslukko" (gear lock) is used for all 100% locks.
