International 923-953

81IH933
79IH943
81IH933ohjaamo
81IH933
79IH943
81IH933ohjaamo
Manufacturer
Models
International 923, International 933, International 943, International 953
Years
1977-84
Info

In 1978, IH introduced the combine harvester models 943 and 953. Of these, the 943 was an improved version of the earlier model 541. Above this was the 953, equipped with a turbocharged engine, longer concaves, and a larger grain tank. For the year 1981, the smaller models 321 and 431 were replaced by the 923 and 933. The growth was mainly in the engine power of the smallest model and the size of the grain tank. At the same time, the grain tank of the 943 was also increased. For the first time, a panoramic cab was now available.

IH's model range is a typical example of development: in a new lineup, the smallest model is dropped, and an ever-larger combine harvester is brought to the top. In the late 1980s, the 953 was also offered as a Hydro version. After these models, IH focused solely on Axial Flow combines.

This is an automated translation. Please report any issues in the translation.

Technical data
ModelInternational 923International 933International 943International 953
Imported to FinlandNoNoNoNo
Years1980-841980-841978-831977-83
EngineIHIHIHIH
Engine typeD-358D-358D-358DT-358/DT-402
Displacement5867 cm³5867 cm³5867 cm³5867/6588 cm³
Cyl/turbo6666T
Power100 hp DIN112 hp DIN125 hp DIN140 hp DIN
Fuel tank200 l230 l230 l270 l
Transmissionmech.mech.mech.mech./hydr.
Gears3333
Speed min-max.1,3-20 km/h1,3-20 km/h1,3-20 km/h1,4-20 km/h
Cutting width300 cm360 cm360 cm360 cm
Cutting width, alternative360, 420 cm300-480 cm300-480 cm420, 480 cm
Reel diameter100 cm100 cm100 cm100 cm
Threshing cyl. diameter56 cm56 cm56 cm56 cm
Threshing cyl. width106 cm131 cm131 cm131 cm
Number of straw walkers4555
Area of walkers365 dm²430 dm²430 dm²520 dm²
Total screening area282334334388
Overall lenght802 cm884 cm887 cm952 cm
Height without cabin372 cm392 cm377 cm377 cm
Weight without header5450 kg6170 kg--
Grain tank32 hl33.7 hl33/38 hl42/46 hl
Tyres front (Finland)16.9-2818.4-3018.4-3023.1-26
Tyres rear (Finland)7.50-167.50-187.50-1810.50-20
Tyres rear, alternative7.50-1813.0-1812-1813.0-18
Reel forward/backw. adjustmenthydr. steeringhydr. steeringhydr. steeringhydr. steering
Reel speed adjustmenthydr. steeringhydr. steeringhydr. steeringhydr. steering
Threshing cyl. speed adjustmenthydr. steeringhydr. steeringhydr. steeringhydr. steering
Bottom sieveadj.adj.adj.adj.
Brakesdisc brakesdisc brakesdisc brakesdisc brakes
Heatingxxxx
Type of cutting platform floatinggas dampergas dampergas dampergas damper
Lenght of walkers-325 cm325 cm395 cm
Width without header-299 cm299 cm299 cm
Tyres front, alternative-23.1-2623.1-2618.4-30
Alternative hp--132 82-> hp150 (Hydro) hp
Weight without cabin--7050 kg7500 kg
